ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7202Q/F/T
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Included)
(Not Included)
Rev:18-09-24
Advertisement
Related Manuals for Furniture of America CM7202Q
Summary of Contents for Furniture of America CM7202Q
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7202Q/F/T ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 4pcs Bolt Ø5/16" x 2-1/4" Headboard Panel #2 x 4pcs #B x 4pcs Bun Feet Lock Washer Ø5/16"...
- Page 4 Exploded View # A x 2pcs #B x 2pcs # C x 2pcs Remove parts from the inside compartment of the headboard (#1). Align legs (#2) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C) Page 4 of 6...
- Page 5 Align legs (#2) to the footboard (#3), then secure by using bolts (#A) with washers (#B,C). # A x 2pcs # B x 2pcs # C x 2pcs Attach metal treads (#F) to the headboard (#1) and footboard (#3), then align the side rails (#4) to the metal treads (#F).
- Page 6 Attach support legs (#6) to the slats (#5), then adjust the leveler on the support legs (#6) according to ground level. Leveler Align slats (#5) to side rails (#4), then secure by using screws (#E). #E x 10pcs Page 6 of 6...
- Page 7 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7202EK/CK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Wrench easy and 5 being difficult).
- Page 8 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 9 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 4pcs Bolt Ø5/16" x 2-1/4" Headboard Panel #2 x 4pcs #B x 4pcs Bun Feet Lock Washer Ø5/16"...
- Page 10 Exploded View # A x 2pcs #B x 2pcs # C x 2pcs Remove parts from the inside compartment of the headboard (#1). Align legs (#2) to the headboard (#1), then secure by using bolts (#A) with washers (#B,C). Page 4 of 6...
- Page 11 Align legs (#2) to the footboard (#3), then secure by using bolts (#A) with washers (#B,C). # A x 2pcs # B x 2pcs # C x 2pcs Attach metal treads (#F) to the headboard (#1) and footboard (#3), then align the side rails (#4) to the metal treads (#F).
- Page 12 Attach support legs (#6) to the slats (#5), then adjust the leveler on the support legs (#6) according to ground level. Leveler Align slats (#5) to side rails (#4), then secure by using screws (#E). #E x 10pcs Page 6 of 6...
