Jet WRT-2000 Specifications And Parts List

WRT-2000 Electric Trolley
This Trolley is designed to run on standard "
flanged "H" beams, or curved track with a minimum radius of 1
meter (39.37 feet).

Specifications

Model Number ..................................................... WRT-2000
Stock Number............................................................107004
Capacity ....................................................................... 1 ton
Motor...................................................... 1/8HP, 110V, 60Hz
Net Weight (lbs.)............................................................... 31
Shipping Weight (lbs.)....................................................... 33
1. Beam must be properly installed and rated for anticipated
loads.
2. Do not install trolley on beams of unknown capacity.
3. Do not install trolley on damaged or deformed beams.
4. JET trolleys are designed to be used with hoists of the
same rated capacity. Never use a hoist with a capacity
greater than the capacity of the trolley.
5. Never subject trolley to a side pull or load. Load must be
centered directly under the hoist/trolley assembly.
6. Make sure load is stable and secure before moving.
7. Never lift load higher than is necessary to safely move it.
8. Do not allow anyone to work or stand beneath a raised load.
9. Always follow installation instructions.
10. Do not use this trolley if you are under the influence of drugs, alcohol or any medication.
11. Do not use in wet, damp or poorly lit location.
12. The electrical plug must be connected to a properly grounded receptacle. If in doubt as to whether a
receptacle is properly grounded, consult a qualified electrician.
WMH TOOL GROUP
2420 Vantage Drive
Elgin, Illinois 60124
Ph.: 800-274-6848
www.wmhtoolgroup.com
I
" beams, wide-
Part No. M-107004
Revision A1 8/06
Copyright © WMH Tool Group
