BASEPLATE OPTIONS - ADHESIVE
1 Route the cable as desired and attach the baseplate with
the included screws.
Routing out
the back
Routing out the bottom
3
Place Micro position in desired location. Press down on
the base plate for 10 seconds for full adhesive contact.
Allow 24 hours for full adhesion.
ADHESIVE POSITION REMOVAL
1
Do not cut power cable.
www.MTIGS.com | T:800.426.6844
2
4
Use the individual power supply and plug it into the
nearest outlet. The socket-outlet shall be installed near
the equipment and shall be easily accessible.
Utilisez l'alimentation individuelle et branchez-la dans la prise la
plus proche. La prise de courant doit être installée à proximité de
l'équipement et doit être facilement accessible.
2
FREEDOM MICRO ® II POWER MANUAL
Peel the red film from the adhesive.
3
MTI P/N 063-00425 rev A ©2022 MTI All Rights Reserved
