Summary of Contents for Gotrax KX5

  • Page 1 K i c k S c o o t e r USER MAN UAL...
  • Page 3 Thank you for your purchase of the KX5 Kick Scooter. Before operating this scooter, please read all instructions. This manual will walk you through the functions, usage, and proper care of your GOTRAX KX5 Kick Scooter. If you have any of purchase or our customer service at canada@gotrax.com...
  • Page 4: Table Of Contents

    Box Contents ........................5 Product Overview ......................6 Assembling the Scooter ....................7 Adjusting the Stem ......................8 Using the Scooter ......................9 Practicing Guidelines ......................10 Safety Information ......................11 Warnings ........................... 12 Warranty Information ......................13 ........................15 KX5 User Manual...
  • Page 5: Box Contents

    Box Contents Handlebar grip x 1 Hoop lock x 1 Main Frame x 1 K i c k S c o o t e r USER MAN UAL Allen Wrench x 1 Screw x 2 User Manual x 1...
  • Page 6: Product Overview

    Product Overview Handlebar grip Foldding latch Tiller Height adjustment Button Height adjustment hole Hoop Lock Foot brake Rear Wheel Deck Front Wheel KX5 User Manual...
  • Page 7: Assembling The Scooter

    Assembling the Scooter 2. Fix the tiller to the head of the main frame. 1. Fix the hoop lock to the bottom of the tiller. 3. Tighten the hoop lock with 2 screws and wrench.
  • Page 8: Adjusting The Stem

    Close the clamp to secure the stem. Note: In order for the scooter to be safe to ride (1) the metal peg must pop into one of the designated holes and (2) the clamp must be closed. KX5 User Manual...
  • Page 9: Using The Scooter

    Using the Scooter An ASTM F1492 approved helmet and protective gear must be worn by ALL riders at ALL times regardless of age. Do not allow user over 110 lbs (50 kg) to ride the scooter. Supervise children while the scooter is being used. Inform your child of instructions and safety guidelines before allowing them to ride.
  • Page 10: Practicing Guidelines

    • Make sure the pavement is even. Do not ride on a slope until you are experienced. • The scooter is designed for relatively smooth, terrain. When riding on uneven terrain, slow down. • Avoid riding in places with pedestrians or obstacles. KX5 User Manual...
  • Page 11: Safety Information

    • The KX5 is a self-propelled scooter designed for a single rider only. It is not intended or equipped for road use, off road use or use with any motorized device.
  • Page 12: Warnings

    • Be careful when riding on wet pavement as braking and wheel traction may be reduced. • Do not modify the scooter or change the scooter in any way not outlined in these instructions. • Screws and xtures may losen over time. Check and tighten periodically. KX5 User Manual...
  • Page 13: Warranty Information

    Warranty Information GOTRAX KX5 Your Kick scooter (“Product”) includes a One Year Limited Hardware Warranty (“Warranty”). The Warranty covers product defects in materials and workmanship under normal use. This Warranty is limited to residents of the United States and Canada only and is available other rights which vary from state to state.
  • Page 14 CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. THE DURATION AND REMEDIES OF ALL IMPLIED WARRANTIES, INCLUDING WITHOUT LIMITATION THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANTY. KX5 User Manual...
  • Page 15 Speci cations PP(handles); ABS,PU(wheels) Material aluminum(deck,steering tube) Scooter Dimensions 24x11x(26.8~31.5)in / 61x28x(68~80)cm 26.8in, 29.1in, 31.5in, / Handlebar Height 68cm, 74cm, 80cm Diameter (Front Wheel) 5in / 12cm Diameter (Rear Wheel) 5in / 12cm Product Weight ~5.5lbs / 2.5kg Maximum Load 110lbs / 50kg Bearings ABEC 5...
  • Page 16 GOLABS, INC G O TRAX.com 22 01 Luna Rd. Ca rrollton, TX 75006...
