GXL V2 E-SCOOTER
H A N D B R A K E
E D I T I O N
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GXL V2 HANDBRAKE EDITION and is the answer not in the manual?

Questions and answers

Related Manuals for Gotrax GXL V2 HANDBRAKE EDITION

Summary of Contents for Gotrax GXL V2 HANDBRAKE EDITION

  • Page 1 GXL V2 E-SCOOTER H A N D B R A K E E D I T I O N USER MANUAL...

  • Page 2: Congratulations On Your Purchase

    CONGRATULATIONS ON YOUR PURCHASE!
  • Page 3 This user manual will help you assemble and operate your new electric scooter. Be sure to read ALL OF THE INFORMATION in this manual before riding. NOTE TO ALL RIDERS UNDER 18 YEARS OF AGE: It’s very important that you get parental permission before riding your electric scooter.
  • Page 4 DON’T RIDE UNTIL YOU READ THIS: ALWAYS wear a helmet when riding your electric scooter. Make sure your scooter has a full battery before taking it out to ride. Always be aware of local road laws, and follow them. Do not ride the scooter under the influence of drugs or alcohol. Always respect pedestrians.

  • Page 5: Warning Message

    2. Abuse - We do not cover physical damage due to negligent care and extreme riding. 3. Whenever you ride the Gotrax Electric Scooter, you risk severe injury or even death from loss of control, collisions, and falls. Use caution and ride at your own risk.
  • Page 6 UNPACK You should find each of these items in your box: 1. Electric Scooter 2. Console & Handlebars 3. Approved Power Adapter / Charging Unit 4. Allen Wrench 5. Tire Pump Extender 6. Safety Pin Remove all packaging material, then inspect each item for any accidental damage that may have occurred during shipping.
  • Page 7 GET TO KNOW YOUR SCOOTER The electric scooter comes partially assembled.

  • Page 8: Assembling Your Scooter

    ASSEMBLING YOUR SCOOTER TOOLS YOU’LL NEED: 4 mm Allen Key Wrench (both included). Unfold scooter Use the Allen wrench to The brake line will be put pressing down on the rear loosen the screws located at into the crevasse on the bot- fender.
  • Page 9 Line up brake line into the Attach the Console to the Tighten the (2) screws pro- (Red) Hook attachment. Tiller. (Line up the pins in the vided. console to the pins on the battery.) Secure the screws. Be sure to check the scooter after assembly to make sure that the scooter is operating cor- rectly.

  • Page 10: Charge Your Scooter

    CHARGE YOUR SCOOTER Before using the scooter, you must fully charge the battery.
  • Page 11 1. Open the rubber charging port cover. 2. Insert the charging plug into the port. 3. The charger box will have a green light when fully charged and a red light when charging. 4. When you are done charging be sure cover the charging port to keep it clear of dust and debris.
  • Page 12 SCOOTER CONSOLE FUNCTIONS To power the scooter on, press and hold the red button for 1 second. To power the scooter off, press and hold the red button for 5 seconds. To power the headlight on or off, press the red button for 1 second while the scooter is powered on.

  • Page 13: Riding Tips

    RIDING TIPS 1. You will want to start riding your electric scooter with one foot on the platform and one foot on the ground. Use your foot on the ground to push off and at the same time, press the throttle button to begin movement. 2.
  • Page 14 PUTTING YOUR SCOOTER AWAY/FOLDING Before folding the scooter, make sure that the scooter is powered off and remove the safety pin. Pull the Tiller towards the back wheel. Insert the hook on the tiller into the loop on the rear fender buckle. You may hear a click which indicates that you were successful in folding and locking the scooter.

  • Page 15: Maintenance And Repair

    MAINTENANCE & REPAIR If you regularly clean and maintain your electric scooter, it will extend its life. Cleaning and storage: If the scooter is dirty, wipe it clean with a soft damp cloth. Brake Adjustments & Service: If you notice you need brake adjustments or any service on your scooter, contact our customer service team and we will adjust and repair your scooter.

  • Page 16: Battery Information

    BATTERY INFORMATION Only use the approved Gotrax power adapter to charge your scooter, others may cause risk of fire & equipment may be damaged. Improper disposal of used batteries may seriously pollute the environment. Please comply with local disposal regulations.

  • Page 17: Troubleshooting

    TROUBLESHOOTING We frequently update our user manuals at gotrax.com, and reserve the rights to update and change manuals online. Please contact our customer service team if you are experiencing problems or need more detailed information. They can be reached at gotrax.com WARRANTY For warranty information, please visit us at www.gotrax.com.
  • Page 19 W W W . G O T R A X . C O M #RIDEGOTRAX...
  • Page 20 GOLABS, INC GoTrax.com 2201 Luna Rd. Carrollton, TX 75006...
