- Page 1 G4 Scooter E L E C T R I C S C O O T E R USER MANUAL...
-
Page 2: Congratulations On Your Purchase
Congratulations on your purchase! This user manual will help you assemble and operate your new electric scooter. Be sure to read ALL OF THE INFORMATION in this manual before riding. NOTE TO ALL RIDERS UNDER 18 YEARS OF AGE: It’s very important that you get parental permission before riding your electric scooter. - Page 3 Don’t Ride Until You Read This: ALWAYS wear a helmet when riding your electric scooter. Make sure your scooter has a full battery before taking it out to ride. Always be aware of local road laws, and follow them. Do not ride the scooter under the influence of drugs or alcohol. Always respect pedestrians.
-
Page 4: Warning Message
2. Abuse - We do not cover physical damage due to negligent care and extreme riding. 3. Whenever you ride the GOTRAX scooter, you risk severe injury or even death from loss of control, collisions, and falls. Use caution and ride at your own risk. - Page 5 Unpack You should find each of these items in your box: 1. Electric Scooter 2. 4 Screws 3. 3mm Allen Wrench 4. Approved Power Adapter / Charging Unit 5. Tire pump extender Remove all packaging material, then inspect each item for any accidental damage that may have occurred during shipping.
-
Page 6: Specifications
Get To Know Your Scooter Accelerator (right thumb throttle) Handbrake (with bell) Display Headlight Switch Button Tiller Folding Mechanism The electric scooter comes partially assembled. Side Reflector Kick Stand Specifications Top Speed: 20 mph Distance per Charge: 21-25 Miles Weight Range Up To: 220lbs Battery Type: 36V 10.4AH... - Page 7 Assemble Your Scooter Straighten the tiller and lift the tiller upright (as shown in the figure). Press the folding lever as the figure shows to lock the tiller. Insert the exposed cable into tiller and then insert the console into the tiller. Use the tool and screws to lock the console into place (as shown in the figure).
-
Page 8: Charge Your Scooter
Charge Your Scooter Before using the scooter, you must fully charge the battery. 1. Open the rubber charging port cover. 2. Insert the charging plug into the port. 3. The charger box will have a green light when fully charged and a red light when charging. - Page 9 Scooter Console Functions Long press power button to power on and off. Hold “+” button for 3 seconds to power the headlight and tail light power on and off. To unlock the display lock the password is 000. Use the “ + “ button to input 0 and press the power button to set.
-
Page 10: Riding Tips
Riding Tips 1. You will want to start riding your scooter with one foot on the platform and one foot on the ground. Use your foot on the ground to push off and at the same time, press the throttle button to begin movement. 2. - Page 11 Putting Your Scooter Away/Folding Before folding the scooter, make sure that the scooter is powered off. . Folding: Ensure the electric scooter is powered off, press the lock buckle as the figure shows and pull down the lever. Fold the tiller down towards the rear fender and lock the tiller hook to the fender hook buckle.
-
Page 12: Maintenance And Repair
Maintenance & Repair If you regularly clean and maintain your electric scooter, it will extend its life. Cleaning and storage: If the scooter is dirty, wipe it clean with a soft damp cloth. Disc Brake Adjustments: If the brake is too tight, use a 4mm Allen wrench to loosen the screws counterclockwise. -
Page 13: Battery Information
Battery Information Only use the approved GOTRAX power adapter to charge your scooter, others may cause risk of fire & equipment may be damaged. Improper disposal of used batteries may seriously pollute the environment. Please comply with local disposal regulations. -
Page 14: Troubleshooting
Troubleshooting We frequently update our user manuals at GOTRAX.com, and reserve the rights to update and change manuals online. Please contact our customer service team if you are experiencing problems or need more detailed information. They can be reached at GOTRAX.com Warranty For warranty information, please visit GOTRAX.com. - Page 15 W W W . G O T R A X . C O M #RideGOTRAX...
- Page 16 GOLABS, INC GOTRAX.com 2201 Luna Rd. Carrollton, TX 75006...
Need help?
Do you have a question about the G4 and is the answer not in the manual?
Questions and answers
Where is the charge port located
@Antonio Carson
The context provided does not specify the exact location of the charge port on the Gotrax G4.
This answer is automatically generated
How to unlock scooter if not password how to unlock scooter how to unlock scooter how to unlock scooter if you for g0t password
To unlock the Gotrax G4 scooter without a password, follow these steps:
1. Unscrew the cable lock from the tiller.
2. Remove the silver plate attached to the backing.
3. Rotate all the numbers until the flat portions of the inner disks align together.
4. Rotate all aligned disks together until the cable lock opens.
If the lock is digital and the password is forgotten, the electronic lock cannot be reset or disabled. In that case, the control unit must be replaced.
