Introduction; Useful Configuration Codes - Code CR2700 User Manual

1. Introduction

Introduction
Code's CR2700 is an advanced wireless 2D barcode reader purpose-built for medical and healthcare
applications. It features inductive charging, the latest Bluetooth
and ergonomic design in combination with superior barcode scanning performance.

2. Useful Configuration Codes

2.1 Scanning the Reset Bluetooth Reader to Factory Defaults barcode below (M20390) will erase
all custom configurations and reset the device to default settings. This will also erase any pairing
information. This, however, will not erase any user settings preprogrammed at factory or any JavaScript
files loaded at factory or by the user.
2.2 Scanning the Reboot Reader barcode below (M20345) will power cycle the device. Note: any settings
that are not saved will be erased.
2.3 The CR2700 supports direct connection as a Bluetooth Keyboard device with third party hosts that
support Bluetooth Low Energy (such as PCs, mobile phones and tablets). Scan the BT HID Keyboard
barcode below (M20381) to set the reader as a Bluetooth Keyboard device, then connect using host's
device manager (on PC) or Bluetooth settings (on mobile devices). Note: this mode is not applicable when
using a Code charger with embedded Bluetooth radio (CRA-A271).
D032263_03_CR2700_User_Manual
® Low Energy standards, and a lightweight
4
