1 – CR822x Introduction
1.1 – Product Overview
The Code Reader™ 822x (CR822x) is a patented, high performance,
miniature barcode imaging engine. The CR822x is the smallest
fully-decoded engine on the market, powered by Code's proprietary
microprocessing platform, which delivers high-speed barcode reading at
a low power point. The CR822x supports RS232 and USB interfaces for
flexible integration into a variety of devices.
1.2 – SKU Descriptions
The following table describes the options available for the CR822x
engine. Any SKU (Part Number) can be built using the following table:
CR822#
Communications
Interface
1 = Single Board USB 0100 = Single Field Optics,
(Ribbon Cable) Standard Focus
2 = Single Board
RS232 (Ribbon Cable)
SKU: CR822# - S#### - MT# - D## - C###
EXAMPLE: CR822x USB with Standard Focus, Tabs,
No Flex, 2.0" Ribbon Cable.
SKU = CR8221-S0100-MT1-DX-C800
Note: Additional Ribbon Cables, Flex Cables, and Focus options may
be available for your application. Please contact your Code representative
to discuss.
D026227_08 CR822x Single Board Decoded Scan Engine Integration Guide
S####
Wide Field/High
Mounting Options
Density Field Focus
X = No Tabs
1= With Tabs
Applications for the CR822x include Medical Devices, ATMs, Price-
Lookup, Lottery, Age Verification, Direct Part Marking, Point of Sale,
Self-Service Kiosks and more.
MT# D##
Flex Cable
X = No Flex Cable
C###
Ribbon Cable
X = No Ribbon Cable
800 = 2.0" Ribbon Cable
801 = 6.0" Ribbon Cable
802 = 12.0" Ribbon Cable
