1 – CR8000 Introduction
1.1 – Product Overview
The Code Reader™ 8000 (CR8000) is a patented, high performance,
miniature barcode imaging engine. The CR8000 continues Code's legacy
of dual optical fields - while most devices have a single field enhanced for
a specific application, the CR8000 has both a high density field for reading
the smallest of barcodes, and a wide angle field for reading oversized
barcodes giving you two readers in one.
The CR8000 includes Code's Glare Reduction Technology. Barcodes printed
on shiny or reflective surfaces have typically been problematic for imaging-
based barcode readers. Code has overcome this challenge with a patented
process that significantly reduces the reflections, thus making the barcodes
easily identifiable. In addition, the CR8000 supports the integration and
control of additional illumination blocks or elements. Example applications
1.2 – SKU Descriptions
The following table describes the options available for the CR8000
Scan Engine. Any SKU (Part Number) can be built using the following table:
SKU: CR8### - L## - MT## - D## - C###
CR801#
Communications Wide Field/High
Interface Density Field Focus
1 = USB 00 = Standard Focus
(Ribbon Cable) WF: 115 mm; HD: 110 mm
2 = RS232
(Ribbon Cable)
3 = USB
(micro-USB Cable)
EXAMPLE: CR8000 USB with Standard Focus,Tabs,
Standard Flex, 2.0" Ribbon Cable.
SKU = CR8011-L00-MT1-D0-C800
Note: Additional Ribbon Cables, Flex Cables, and Focus options may
be available for your application. Please contact your Code representative
to discuss.
C005383_10 CR80XX Integration Guide
L## MT#
Mounting Options
X = No Tabs
or Brackets
1= With Tabs;
No Bracket
(see Section 2.1)
2 = With Tabs and
Standard Bracket
(see Section 2.2)
that benefit from the expanded illumination are document scanning and
direct part marking.
For mechanical integration, a variety of mounting options are available
including tabs, blind through-holes, and mounting brackets for both the
Scan Engine and the decode board. The CR8000 communicates via RS232
or USB protocols.
Applications for the CR8000 include Medical Devices, ATMs, Price-Lookup,
Lottery, Age Verification, Direct Part Marking, Point of Sale, Self-Service
Kiosks and more.
D#
Flex Cable
X = No Flex Cable X = No Ribbon Cable
0 = Standard Flex Cable 800 = 2.0" Ribbon Cable
1 = Reverse Flex Cable 801 = 6.0" Ribbon Cable
(for Bracket Mount)
2 = In-Line Flex Cable 802 = 12.0" Ribbon Cable
C###
Ribbon Cable
(CR8011/CR8012 only)
