- Page 1 Installation Guide Smartlink Series...
-
Page 2: Package Contents
10k Smartlink Package Contents Indoor Antenna Outdoor Cable Indoor Cable Outdoor Cable Signal Booster Outside Antenna 32.8ft NM-SMAM 16.4ft SMAF-NM 30ft NM-NM 3M waterproof tape Through-Window Cable Power Supply Accessories for main parts Bluetooth and are all provided SMA-Male to SMA-Female to protect connections Wi-Fi antenna (No drilled hole) - Page 3 Step 3 Find the cell tower & Determine the outdoor antenna’s position 3.1 Find the b and you are using For Android Download NetWork Cell Info Lite in the Google store and open it. It can be seen that the frequency band is band 13 from the example picture. Then click MAP.
- Page 4 3.2 Find the cell tower (1)Enter cellmapper.net (2)Choose your own carrier and band here. (3) Then enter the coordinate of where you are trying to install the signal booster, and press Enter key. (In fact when you open Cellmapper, the map on the right will automatically locate your area if you've given the site permission to access your location.
- Page 5 Step 4 Connect the outdoor antenna with the booster Note：At this stage, don’t connect the indoor antenna to the booster. 32.8 Step 5 Adjust and fix the Outdoor Antenna Have your outdoor antenna pointed to the cell tower you found before and watch the readings on the app.
- Page 6 Step 7 Adjust the indoor antenna 65dB Have your indoor antenna pointed to the area you would like to cover with signal. Notes: (1)It would be best if you could make the two antennas face opposite directions. (2)Make sure that the gain reaches 65dB. If not, please adjust the direction of the indoor antenna/increase the vertical and horizontal distance between the two antennas/add some barriers.
- Page 7 Step 9 Fix the Inside Antenna and the Booster Fix the indoor antenna with the provided expansion bolt and hook. Fix the booster with the provided expansion bolt and hook. 4 Regular Problems and 1 normal status (DL)Output LED Light (UL)Gain (DL)Gain Reason...
- Page 8 Bands contained in the Gauges Gauge Band Uplink Downlink 12/17 698-716MHz 728-746MHz LTE700 776-787MHz 746-757MHz CELL800 824-849MHz 869-894MHz PCS1900 25/2 1850-1915MHz 1930-1995MHz AWS2100 1710-1755MHz 2110-2155MHz Note: Some customers have some misunderstandings about boosters, and we would like to clarify it here. If you can't even get a stable 1 bar outside the house or on the roof, then we suggest you return it as it won't work in areas with very weak signal, the same is true of all boosters on the market.
-
Page 9: Technical Specifications
IP40 Power Supply Input AC 100~240V, 50/60Hz, Output DC 12 V/3 A For more information Download Signal Supervisor or enter our website. www.hiboost.com. a. You can download the specific user manual. b. You can reach our technical support for help. - Page 10 3150 Premier Drive,Suite 130, Irving, TX 75063 (972) 870-5666 service@hiboost.com www.hiboost.com...
