Summary of Contents for HiBoost SLD+
-
Page 3: How It Works
HOW IT WORKS Huaptec digital repeater is actually a mobile communication signal relay amplification device with the same frequency. It has two separate internal amplification links, uplink (or forward link) and down link (or reverse link). Downlink receives signals from BTS (Adopt donor antenna and BTS by air coupling), send the signals to coverage area after amplification. - Page 4 Figure 2: Monitoring function diagram Repeater Introduction Hiboost SLD+ is a full duplex mobile communications repeater that is designed for indoor operations and used to enhance signal strength in small-and-medium sized areas in a 700MHZ,800MHz, 1900MHz and 2100MHz network. It is the...
-
Page 7: How To Install Your Signal Booster
Equipment Ports description I Connector Description BS/ BTS N-female connector, for connection to donor antenna N-female connector, for connection to service antenna Antenna For connection to modem antenna. Debug Local debug by MDS Software, for connection to USB cable. Local control andmonitoring by OMT Software,for connection Local to USB cable. -
Page 17: Fcc Rf Exposure Statement
•Check whether it is necessary to add one or more antennas to enhance the coverage of special areas. FCC RF Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled enviroment. This equipment should be installed and operated with minimum distance 40cm between the radiator and your body. - Page 18 H"1oosT electric shock. & Do not open the booster, touch the module of booster, or open the cover of module to touch the electronic component. The components will be damaged due to electrostatic. 必 Please keep away from heating-equipment, because the booster will dissipate heat during working.
- Page 19 WARNING: This is NOT a CONSUMER device. It is designed for installation by an installer approved by an ISED licensee. You MUST have an ISED LICENCE or the express consent of an ISED licensee to operate this device. Link to CPC-2-1-05 http://www.ic.gc.ca/eic/site/smt-gst.nsf/ e ng/sf08942.html...
