Page 7
SU-1o 功能介绍 NPUTS (输入方式) USB TYPE B (USB TYPE B输入) USB TYPE C (USB TYPE C输入) BLUETOOTH (蓝牙输入) OPTICAL (光纤输入) COAXIAL (同轴输入) AES/EBU (蓝牙输入) I2S(HDMI) (I2S输入) PUTS (输出方式) ALL LINE OUT (全部输出) BALANCED (平衡输出) UNBALANCED (单端输出) PCM FILTER (PCM滤波器) Fast Linear (快速滚降,...
Page 8
Fast Linear Slow Linear Fast Minimum Slow Minimum Fast Hybrid Apodizing Brickwall DSD FILTER (DSD滤波器) DSD总共有4种数字滤波方式, 它的作用是数字运算的方式把音频外的杂波过滤掉, 分别为: 47kHz Cutoff ( 47kHz 频率截止) 50kHz Cutoff ( 50kHz 频率截止) 60kHz Cutoff ( 60kHz 频率截止) 70kHz Cutoff ( 70kHz 频率截止) SOUND COLOR(音色菜单) 本机总共有9种音色模式,...
Page 9
SU-1o 功能介绍 PRE MODE(前级模式) PRE MODE为输出接口的音量调节功能开关: Variable:输出接口音量是受控的。 Fixed:输出接口音量是固定的。 FN KEY FOR FN按钮 Outputs (输出选择) Bluetooth(蓝牙输入) DPLL DPLL 设置) MIN ~ MAX (共15种, 默认为5。 数字越大适应抖动的范围越强, 数字越小抗时钟抖动的性能 越好。 ) 这个DPLL设定是ESS系列产品特有的功能, 它可以调整芯片内部DPLL数字锁相环电 路的带宽, 使芯片在抗时钟抖动和输入宽容度之间达到一个平衡。 它的作用: 在输入信号的时钟稳定度好的情况, 可以减小这个值, 这样系统的时钟性能更佳; 在输入信号的时钟稳定度不好的情况下, 声音有可能会有中断的现象, 增大这个 值可以避免声音中断现象的发生! 特别是使用电视作为信号源时。...
Page 10
SU-1o 功能介绍 I2S MODE 自动熄屏 NORMAL(常规相位) REVERSED(反相) S DATA + S DATA - S DATA - S DATA + S BCK + S BCK + S BCK - S BCK - S LRCLK + S LRCLK - S LRCLK - S LRCLK + S MCLK + S MCLK +...
Dismantling, refitting, repairing by user in private. Causing damage by using some fittings instead of the designative or accredited ones. Cannot provide credible proof of purchase. 4.Sending it back to our company for repairing. 5.Contact your S.M.S.L Audio reseller for a return or replacement.
Page 14
Two sets of linear power are used to supply to the digital and analog units respectively. Equipped with multiple low-noise regulated power for providing SU-10 a stable, reliable, efficient and low-noise power supply system; Qualcomm's latest Bluetooth chip supports LDAC, APTX/HD, SBC, AAC;...
SU-1o Remote control Install 2 x AAA batteries as instructions. When using the remote control, point it toward the remote con-trol signal receiver on the main unit from a distance of 5 m (16 ft) or less. Do not place obstructions between the main unit and the remote control.
Page 17
Clear pairing: Long press the "Bluetooth" button on the remote control. After clearing the pairing, some phones may no longer be able to search for "SMSL SU-10". In this case, you need to delete the Bluetooth device "SMSL SU-10" which saved in...
Page 18
SU-1o Instructions NPUT USB TYPE B USB TYPE C BLUETOOTH OPTICAL COAXIAL AES/EBU I2S(HDMI) OUTPUT ALL LINE OUT BALANCED UNBALANCED PCM FILTER Fast Linear Slow Linear Fast Minimum Slow Minimum Apodizing Fast Hybrid Brickwall...
Page 19
47kHz Cutoff 50kHz Cutoff 60kHz Cutoff 70kHz Cutoff SOUND COLOR There are 9 sound color settings in SU-10. Rich1、 Rich2、 Rich3 Tube1、 Tube2、 Tube3 Crystal1、 Crystal2、 Crystal3 This setting is usingthe DSP of ES9038PRO,to make some different sound color, all of these settings will not change the frequency res ponse curve.When set to "Standard",...
Page 20
PRE MODE Volume control enable or disable. Vol Fixed : In this mode, volume is fixed on max output level, and the SU-10 will ignore the volume operations. Vol Variable: In this mode, volume can be adjust by remote controller, and make SU-10 a pre-amplifier.
Page 21
SU-1o Instructions S MODE NORMAL REVERSED S DATA + S DATA - S DATA - S DATA + S BCK + S BCK + S BCK - S BCK - S LRCLK + S LRCLK - S LRCLK - S LRCLK + S MCLK + S MCLK + S MCLK -...
Page 22
SU-1o Instructions DIMMER 5 seconds ~ 60 seconds (The range is 5 seconds-60 seconds. After setting, the screen will automatically go off within this time, and the screen will re-light up if you operate the remote control or the knob at any time.) BRIGHTNESS LEVEL 1 ~ LEVEL 6...
