ADJ Freq Matrix Quad User Instructions page 9

FREQ Matrix Quad
Channel Value
9
0 - 255
10
0 - 255
11
0 - 255
12
0 - 255
13
0 - 255
14
0 - 255
15
0 - 255
16
0 - 255
17
0 - 255
18
0 - 15
16 - 131
132 - 139
140 - 181
182 - 189
190 - 231
232 - 239
240 - 247
248 - 255
ADJ Products, LLC - www.adj.com - FREQ Matrix Quad Instruction Manual Page 16
18 Channel Mode
Function
RED (3rd Row)
0% - 100%
GREEN (3rd Row)
0% - 100%
BLUE (3rd Row)
0% - 100%
WHITE (3rd Row)
0% - 100%
RED (4th Row)
0% - 100%
GREEN (4th Row)
0% - 100%
BLUE (4th Row)
0% - 100%
WHITE (4th Row)
0% - 100%
MASTER DIMMER
0% - 100%
STROBING
OPEN
STROBING SLOW - FAST
OPEN
SLOW OPEN - FAST CLOSE
OPEN
FAST OPEN - SLOW CLOSE
OPEN
SOUND ACTIVE STROBING
OPEN
FREQ Matrix Quad
Channel Value
1
0 - 255
2
0 - 255
3
0 - 255
4
0 - 255
5
0 - 255
6
0 - 255
7
0 - 255
8
0 - 255
*Channels 9-56 continue the same RGBW LED Pattern*
57
0 - 255
58
0 - 255
59
0 - 255
60
0 - 255
61
0 - 255
62
0 - 255
63
0 - 255
64
0 - 255
ADJ Products, LLC - www.adj.com - FREQ Matrix Quad Instruction Manual Page 17
64 Channel Mode
Function
RED 1
0% - 100%
GREEN 1
0% - 100%
BLUE 1
0% - 100%
WHITE 1
0% - 100%
RED 2
0% - 100%
GREEN 2
0% - 100%
BLUE 2
0% - 100%
WHITE 2
0% - 100%
RED 15
0% - 100%
GREEN 15
0% - 100%
BLUE 15
0% - 100%
WHITE 15
0% - 100%
RED 16
0% - 100%
GREEN 16
0% - 100%
BLUE 16
0% - 100%
WHITE 16
0% - 100%
