Summary of Contents for Arbor Technology Em104P-i6023
Page 1
All manuals and user guides at all-guides.com User's Manual Version 1.1 Em104P-i6023 Intel Celeron ULV 400MHz board with VGA/LCD, TV-out, audio, dual Ethernet, CF socket, PC/104 and PC/104 Plus interface...
Page 3
All manuals and user guides at all-guides.com Warning Single Board Computers and their components contain very delicate Integrated Circuits (IC). To protect the Single Board Computer and its components against damage from static electricity, you should always follow the following precautions when handling it : 1.
Page 4
All manuals and user guides at all-guides.com Specifications System • CPU : Intel Ultra Low Voltage Embedded Celeron 400MHz to Pentium3 933MHz processor with FSB 100/133 MHz EBGA package. • Chipset : VIA VT8606 TwisterT with Integrated Savage4 AGP 4X Graphics core and VT82C686B Super "South Bridge"...
Page 5
All manuals and user guides at all-guides.com Display Controller • Chipset : 4x AGP S3 Savage4 3D and S3 Savage 2000 2D engines integrated in VT8606 supports up to 32MB of Shared Memory • Display Type : Flat Panel and CRT displays up to 1280x1024 @ 32 bpp - Lcd interface : Flat Panel 36-bit TFT/DSTN interface - LVDS interface(PBE-1000) : Scalable Bandwidth is ranging from 25MHz~112MHz(VGA~SXGA) 18/36-bit one/two channel LVDS interface...
Page 6
Packing list Before you begin installing your single board computer, please make sure that the following materials have been shipped: > 1 x Em104P-i6023 > 1 x Quick Installation Guide > 1 x CD-ROM ( for driver used) > 1 x Warranty Card...
Page 7
All manuals and user guides at all-guides.com Packing list Packing list Packing list Packing list Packing list Before you begin installing your single board computer, please make sure that the following materials have been shipped: > 1 x EmETX-i602 EXT Embedded Intel Celeron(or PIII Tulatin) SBC >...
Page 8
All manuals and user guides at all-guides.com Board Dimension...
Page 11
All manuals and user guides at all-guides.com Jumper/Connector in Top Side Connectors Lable Function Page LCD1 LCD TTL Connector 1 LCD2 LCD TTL Connector 2 ETX1 PCI Bus, USB, Audio ETX2 ISA Bus ETX3 VGA,LCD,Video,COM1,COM2,LPT,IrDA,M/K ETX4 IDE1,IDE2,Ethernet,Miscellaneous...
Page 12
All manuals and user guides at all-guides.com Flat Panel VGA LCD1 Type : Onboard 40-pin Box Header (Hirose DF-40DS-1.25C) Description Description VCC5V VCC5V VCC3V VCC3V FPD0 FPD1 FPD2 FPD3 FPD4 FPD5 FPD6 FPD7 FPD8 FPD9 FPD10 FPD11 FPD12 FPD13 FPD14 FPD15 FPD16 FPD17...
Page 13
All manuals and user guides at all-guides.com Jumper/Connector in Back Side Label Function INV1 LCD Inverter connector LVDS1 LVDS Connector (30 pin) TV-Out PWR1 Power terminator/6P Power Connector IDE1 Primary IDE Connector CFD1 Compact Flash socket (shared with 2nd IDE Master) VGA1 VGA Display Connector Infrared (IR) Connector...
Page 14
All manuals and user guides at all-guides.com CMOS Jumper Settings CMOS Setup (JBAT1) JB AT 1 Type : JBAT1: onboard 3-pin header CMOS Setup (JBAT1) JBAT1 Keep CMOS Clear CMOS default setting : Keep CMOS Serial Port Selection (RS232C/422/485) RS-232C/422/485 Mode on COM2 (JRS2) The onboard COM2 port can be configured to operate in RS-232C mode or in different RS-422/485 modes.
Page 15
All manuals and user guides at all-guides.com Watchdog Timer Watchdog Output (JWT) J W T Mode Setting Watchdog Mode Enabled for Active NMI(I/O Channel Check) Enabled for System Reset Disable Watchdog Timer None default setting Enabled LVDS Voltage Seletion LVDS Operation (JVLCD1) Type : onboard 3-pin dip switch 3 2 1 J V L C D1...
Page 16
All manuals and user guides at all-guides.com LCD Inverter Connector 1 2 3 4 5 Connector : INV1 Type : Onboard 5-pin mini boxheader Description Description +12 V BLON LVDS LCD Connector Connector : LVDS1 Type : onboard DF-13-30P-1.25V LVDS1 TX1CLK+ TX2CLK+ TX1CLK-...
Page 17
All manuals and user guides at all-guides.com TV-out Connector Connector : TV1 (Function not available in Em104P-i7013) Type: Onboard 6-pin mini boxheader Description TV_COMP TV_Y TV_C Power Connector PW R1 Connector : PWR1 Type : onboard 6-pin Terminator +5 V Description +5 V +12V...
Page 18
All manuals and user guides at all-guides.com Enhanced IDE Connector Connector : IDE1 Type : One onboard 44-pin box headers, primary IDE Description Description #RESET #IOW #IOR #IORDY IDESEL #DACK NC (-IOCS16) ADDR1 CBLID ADDR0 ADDR2 #CS1 #CS3(#HD SELECT1) #ACT...
Page 19
All manuals and user guides at all-guides.com Compact Flash Connector Connector : CFD1 Type : 50-pin compact flash type I/II (Share 2nd IDE Master) Description Pin Description Pin Description 1 8 ADDR2 3 5 IO WRITE DATA3 1 9 ADDR1 3 6 +5V DATA4 2 0 ADDR0...
Page 20
All manuals and user guides at all-guides.com VGA Connector Connector : VGA1 VGA1 Type: Onboard 16-pin mini boxheader Description Pin Description Pin Description 1 1 NC GREEN 1 2 VDDAT BLUE 1 3 HSYNC 1 4 VSYNC 1 5 VDCLK IrDA Connector 5 4 3 2 1 Connector : IR1...
Page 21
All manuals and user guides at all-guides.com COMA & COMB Connector Connector : COMA RS232 Serial Port Connector (COM1,COM2) Type : onboard 2x10-pin box header Description Description DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1 DCD2 RXD2 TXD2 DTR2 DSR2 RTS2 CTS2 Connector : COMB RS232 Serial Port Connector (COM3,COM4) Type : onboard 2x10-pin box header...
Page 22
All manuals and user guides at all-guides.com Parallel Port Connector : LPT1 Type : onboard 26-pin box header L PT1 Description Description #STROBE #AUTO FEED DATA0 #ERROR DATA1 #INITIALIZE DATA2 #SELECT INPUT DATA3 DATA4 DATA5 DATA6 DATA7 #ACKNOWLEDGE BUSY PAPER EMPTY SELECT USB Connector Connector: USB1, USB2...
Page 23
All manuals and user guides at all-guides.com Audio Interface Connector : Audio1 Type : Onboard 10-pin box header Audio1 Description Description LINE IN LEFT LINE IN RIGHT SPEAKER LEFT SPEAKER RIGHT Fast Ethernet Connectors LAN Port (10/100Mbps) Connector : LAN1 & LAN2 L A N 1 Type : Two 2x5 pin header for LAN ports Desciption...
Page 24
All manuals and user guides at all-guides.com 8-bit Digital I/O Connector : DIO1 Type : Onboard 20-pin header Description Description +12V Output I/O Address :208H Input I/O Address:200H System Fan Connector 1 2 3 Connector : FAN1 Type : onboard 3-pin header FAN1 Description...
Page 25
All manuals and user guides at all-guides.com Switches and Indicators RESET PLED+ PLED- HLED+ HLED- Connector : JFRT1 SPK+ SPK- Type : onboard 10-pin header EXTSMI Description 9 10 Reset Power LED HDD LED Exteranal speaker 9-10 External SMI...
