Arbor Technology EmCORE-i65M3 User Manual

3.5" compact board
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
EmCORE-i65M3
3.5" Compact Board
User's Manual
Version 1.0
2012.08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EmCORE-i65M3 and is the answer not in the manual?

Questions and answers

Related Manuals for Arbor Technology EmCORE-i65M3

Summary of Contents for Arbor Technology EmCORE-i65M3

  • Page 1 EmCORE-i65M3 3.5” Compact Board User’s Manual Version 1.0 2012.08...
  • Page 2 This page is intentionally left blank.

  • Page 3: Table Of Contents

    Index Contents Chapter 1 - Introduction ............1 1.1 Copyright Notice ............2 1.2 Declaration of Conformity ...........2 1.3 About This User’s Manual ...........4 1.4 Warning .................4 1.5 Replacing the Lithium Battery........4 1.6 Technical Support ............4 1.7 Warranty ................5 1.8 Packing List ..............6 1.9 Ordering Information ............6 1.10 Specifications .............7 1.11 Board Dimensions ............8...
  • Page 4 Index CON1: RS-422/ 485 Connector ........29 PWR2: SATA Power Connector ........30 CPUF1: CPU Fan Connector ........31 COM1: Serial Port Connector ........32 LVDS1: LVDS Connector ..........33 INV1: LCD Inverter Connector ........35 DVI1: DVI Connector .............36 USB3: USB Port Connectors ........38 LAN1, 2: Gigabit Ethernet Connectors .......39 MC1: Mini-card Socket ..........40 DIMM1: SO-DIMM Socket ..........41 CF1: CFast Socket ............42...
  • Page 5 3.7 AMI BIOS Checkpoints ..........81 3.7.1 Checkpoint Ranges ..........81 3.7.2 Standard Checkpoints .........82 Appendix .................90 Appendix A: I/O Port Address Map .........91 Appendix B: Interrupt Request Lines (IRQ) ....94 Appendix C: BIOS Memory Map ........95 - III -...
  • Page 6 This page is intentionally left blank. - IV -...

  • Page 7: Chapter 1 Introduction

    Introduction Chapter 1 Introduction Chapter 1 - Introduction - 1 -...

  • Page 8: Copyright Notice

    Introduction 1.1 Copyright Notice All Rights Reserved. The information in this document is subject to change without prior notice in order to improve the reliability, design and function. It does not represent a commitment on the part of the manufacturer. Under no circumstances will the manufacturer be liable for any direct, indirect, special, incidental, or consequential damages arising from the use or inability to use the product or documentation, even if advised of the possibility of such...
  • Page 9 RoHS ARBOR Technology Corp. certifies that all components in its products are in compliance and conform to the European Union’s Restriction of Use of Haz- ardous Substances in Electrical and Electronic Equipment (RoHS) Directive 2002/95/EC.

  • Page 10: About This User's Manual

    Introduction 1.3 About This User’s Manual This user’s manual provides general information and installation instructions about the product. This User’s Manual is intended for experienced users and integrators with hardware knowledge of personal computers. If you are not sure about any description in this booklet. please consult your vendor before further handling.

  • Page 11: Warranty

    Introduction 1.7 Warranty This product is warranted to be in good working order for a period of two years from the date of purchase. Should this product fail to be in good working order at any time during this period, we will, at our option, replace or repair it at no additional charge except as set forth in the following terms.

  • Page 12: Packing List

    Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EmCORE-i65M3 3.5" Compact Board with heatsink 1 x Driver CD 1 x Quick Installation Guide If any of the above items is damaged or missing, contact your vendor immediately.

  • Page 13: Specifications

    Introduction 1.10 Specifications Form Factor 3.5" Compact Board Soldered onboard Intel® Sandy Bridge Celeron™ 827E 1.4GHz processor Chipset Intel® PCH HM65 1 x 204-pin DDR3 SO-DIMM socket supporting System Memory 1066/800MHz SDRAM up to 4GB Integrated Intel® HD Graphics 3000 supporting 24-bit dual Graphics channels LVDS and DVI-I Ethernet...

  • Page 14: Board Dimensions

    Introduction 1.11 Board Dimensions Unit: mm - 8 -...

  • Page 15: Chapter 2 Installation

    Installation Chapter 2 Installation Chapter 2 - Installation - 9 -...

  • Page 16: Block Diagram

    Installation 2.1 Block Diagram Soldered onboard DDR3-1600/1333/1066MHz 1 x DDR3 SO-DIMM socket Intel® Celeron 827E Power Processor DC input +12V only DMI2 (x4) Analog RGB Dual Channels 24-bit LVDS 1 x DVI-I 1 x LVDS Connector Chrontel Display Port C CH7318C 2 x SATA ports Level shifter to DVI...

  • Page 17: Jumpers

    Installation 2.2 Jumpers JBAT1 JPWR1 JVLCD1 JRS1 - 11 -...

  • Page 18: Connectors

    Installation 2.3 Connectors 27 SIM1 26 CF1 PWR1 SMBUS1 25 LAN1 JLPC1 BAT1 24 LAN2 28 MC1 JFRT1 (Bottom Side) 23 USB3 AUDIO1 11 USB1 12 USB2 13 COM2 22 DVI1 DIMM1 14 SATA2 (Bottom Side) 21 INV1 15 SATA1 20 LVDS1 16 CON1 19 COM1...

  • Page 19: Jumpers

    Installation Jumpers JBAT1: Clear CMOS Setting (1) If the board refuses to boot due to inappropriate CMOS settings here is how to proceed to clear (reset) the CMOS to its default values. Connector type: 2.00mm pitch 1x3-pin headers Mode Keep CMOS (Default) Clear CMOS You may need to clear the CMOS if your system cannot boot up because you forgot your password, the CPU clock setup is incorrect, or the CMOS settings...
  • Page 20 Installation JBAT1 - 14 -...

  • Page 21: Jpwr1: At/Atx Power Mode Selection

    Installation JPWR1: AT/ATX Power Mode Selection (2) The power mode jumper selects the power mode for the system. Connector type: 2.54mm pitch 1x3-pin headers. Mode AT Mode ATX Mode (Default) JPWR1 - 15 -...

  • Page 22: Jrs1: Com2 Rs-232/422/485 Mode Selection

    Installation JRS1: COM2 RS-232/422/485 Mode Selection (3) The onboard COM2 port can be configured to operate in RS-422 or RS-485 modes. RS-422 modes differ in the way RX/TX is being handled. Jumper JRS1 switches between RS-232 or RS-422/485 mode. All RS-232/422/482 modes are available on COM2.
  • Page 23 Installation JRS1 - 17 -...

  • Page 24: Jvlcd1: Lvds1 Lcd Panel Voltage Selection

    Installation JVLCD1: LVDS1 LCD Panel Voltage Selection (4) The voltage of LCD panel could be selected by JVLCD1 in +5V or +3.3V. Connector type: 2.54 mm pitch 1x3-pin headers Voltage +3.3V (Default) JVLCD1 - 18 -...

  • Page 25: Connectors

    Installation Connectors PWR1: +12V Connector (5) PWR1 supplies the CPU operation at +12V (Vcore). Description Description +12V +12V PWR1 - 19 -...

  • Page 26: Smbus1: External Smbus Connector

    Installation SMBUS1: External SMBUS Connector (6) Connector type: 2.54mm pitch 1x3-pin box wafer connector. Description Data Clock SMBUS1 - 20 -...

  • Page 27: Jlpc1: Low Pin Count Connector

    Installation JLPC1: Low Pin Count Connector (7) Connector type: 2.00mm pitch 2x10-pin headers Description Description LPC_LDRQ# LPC_FRAME# INT_SERIRQ LPC_AD2 LPC_AD3 LPC_AD0 LPC_AD1 PLT_RST# SMB DATA CLK 33MHz SMB CLK CLK 48MHz PME# JLPC1 - 21 -...

  • Page 28: Bat1: Battery Holder

    Installation BAT1: Battery Holder (8) Description Battery power BAT1 Battery power BAT1 - 22 -...

  • Page 29: Jfrt1: Switches And Indicators

    Installation JFRT1: Switches and Indicators (9) It provides connectors for system indicators that provides light indication of the computer activities and switches to change the computer status. Connector type: 2.00 mm pitch 2x5-pin headers Description Description RESET+ RESET- PLED+ PLED- HLED+ HLED-- SPEAK+...
  • Page 30 Installation JFRT1 - 24 -...

  • Page 31: Audio1: Audio Connector

    Installation AUDIO1: AUDIO Connector (10) Connect a tape player or another audio source to the light blue Line-in connector to record audio on your computer or to play audio through your computer’s sound chip and speakers. Connect a micro-phone to the pink microphone connector to record audio to your computer.

  • Page 32: Usb1, 2: Usb Connectors

    Installation USB1, 2: USB Connectors (11, 12) The CPU board on board supports two headers USB1, USB2 that can connect up to 4 high-speed (Data transfers at 480Mb/s), full-speed (Data transfers at 12Mb/s) or low-speed (Data transfers at 1.5Mb/s) USB devices. Connector type: 2.54mm 2x5-pin headers Description Description...

  • Page 33: Com2: Serial Port Connector

    Installation COM2: Serial Port Connector (13) Connector type: 2.00mm pitch 2x5-pin box header. Description Description DCD#2 RXD2 TXD2 DTR#2 DSR#2 RTS#2 CTS#2 COM2 - 27 -...

  • Page 34: Sata1,2: Serial Ata Connectors

    Installation SATA1,2: Serial ATA Connectors (14, 15) There are on board two SATA connectors, third generation SATA drives transfer data at speeds as high as 600MB/s, twice the transfer speed of first generation SATA drives. Description SATA2 SATA1 - 28 -...

  • Page 35: Con1: Rs-422/ 485 Connector

    Installation CON1: RS-422/ 485 Connector (16) Connector type: 2.00mm pitch 1x4 box wafer connector RS-422 RS-485 422TX+ Data+ 422TX- Data- 422RX+ 422RX- CON1 - 29 -...

  • Page 36: Pwr2: Sata Power Connector

    Installation PWR2: SATA Power Connector (17) Connector type: 2.54mm pitch 1x4-pin wafer one wall connector Description +12V PWR2 - 30 -...

  • Page 37: Cpuf1: Cpu Fan Connector

    Installation CPUF1: CPU Fan Connector (18) CPUF1 is a 3-pin header for the CPU fan. The fan must be a +12V fan. Description +12V FAN_Detect CPUF1 - 31 -...

  • Page 38: Com1: Serial Port Connector

    Installation COM1: Serial Port Connector (19) Connector type: D-Sub 9-pin male. Description Description DCD#1 DSR#1 RXD1 RTS#1 TXD1 CTS#1 DTR#1 COM1 - 32 -...

  • Page 39: Lvds1: Lvds Connector

    Installation LVDS1: LVDS Connector (20) Connector type: DF-13-30DP-1.25V Description Description TX2_CLK+ TX1_CLK+ TX2_CLK- TX1_CLK- TX2_D0+ TX1_D0+ TX2_D0- TX1_D0- TX2_D1+ TX1_D1+ TX2_D1- TX1_D1- TX2_D2+ TX1_D2+ TX2_D2- TX1_D2- TX2_D3+ TX1_D3+ TX2_D3- TX1_D3- - 33 -...
  • Page 40 Installation LVDS1 - 34 -...

  • Page 41: Inv1: Lcd Inverter Connector

    Installation INV1: LCD Inverter Connector (21) Connector type: 2.00mm pitch 1x5-pin box wafer connector. Description +12V on/off Brightness control INV1 - 35 -...

  • Page 42: Dvi1: Dvi Connector

    Installation DVI1: DVI Connector (22) Connector type: DVI-I female. DVI-I Connector Description Description Description DATA2- DATA1- DATA0- DATA2+ DATA1+ DATA0+ DATA 2/4 DATA 1/3 DATA 0/5 SHIELD SHIELD SHIELD DATA 4- (LINK DATA 3- (LINK DATA 5- (LINK 1, NC 1, NC 1, NC DATA 4+ (LINK...
  • Page 43 Installation DVI1 - 37 -...

  • Page 44: Usb3: Usb Port Connectors

    Installation USB3: USB Port Connectors (23) Connector type: double stack USB type A. USB2 - 38 -...

  • Page 45: Lan1, 2: Gigabit Ethernet Connectors

    Installation LAN1, 2: Gigabit Ethernet Connectors (25, 24) These connectors support Gigabit Ethernet. LAN1 LAN2 - 39 -...

  • Page 46: Mc1: Mini-Card Socket

    Installation MC1: Mini-card Socket (28, Bottom side) MC1 (Bottom side) - 40 -...

  • Page 47: Dimm1: So-Dimm Socket

    Installation DIMM1: SO-DIMM Socket (29, Bottom side) DIMM1 DIMM1 (Bottom side) - 41 -...

  • Page 48: Cf1: Cfast Socket

    Installation CF1: CFast Socket (26) Description SGND1 SGND2 SGND LED1 PC17 LED2 PC10 PC11 PC12 PC13 3.3V PC14 3.3V PC15 PC16 PC17 - 42 -...
  • Page 49 Installation - 43 -...

  • Page 50: Sim1: Sim Card Socket

    Installation SIM1: SIM Card Socket (27) Connector type: Foxconn WL618E2-U05-7F CX1 socket Description SIM1 - 44 -...

  • Page 51: The Installation Paths Of Cd Driver

    Installation 2.6 The Installation Paths of CD Driver Windows XP Driver Path CHIPSET \CHIPSET \GRAPHICS\WinXP AUDIO \AUDIO\WinXP_ALC662 \ETHERNET\WinXP_82583V Framework \NET Framework Windows 7 Driver Path CHIPSET \CHIPSET \GRAPHICS\Win7 AUDIO \AUDIO\Win7_ALC662 \ETHERNET\Win7_82583V Intel Turbo \CPU_utility - 45 -...
  • Page 52 Installation This page is intentionally left blank. - 46 -...

  • Page 53: Chapter 3 - Bios

    BIOS Chapter 3 BIOS Chapter 3 - BIOS - 47 -...

  • Page 54: Bios Main Setup

    BIOS 3.1 BIOS Main Setup The AMI BIOS provides a setup utility program for specifying the system configurations and settings which are stored in the BIOS ROM of the system. When you turn on the computer, the AMI BIOS is immediately activated. After you have entered the setup utility, use the left/right arrow keys to highlight a particular configuration screen from the top menu bar or use the down arrow key to access and configure the information below.

  • Page 55: Advanced Settings

    BIOS System Date Set the system date. Note that the ‘Day’ automatically changes when you set the date. The date format is: Day : Sun to Sat Month : 1 to 12 Date : 1 to 31 Year : 1999 to 2099 System Time Set the system time.

  • Page 56: Acpi Configuration

    BIOS 3.2.1 ACPI Configuration Enable Hibernation Enable or disable System ability to Hibernation (OS/S4 Sleep State). This op- tion may be not effective with some OS. ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed.

  • Page 57: Cpu Configuration

    BIOS 3.2.2 CPU Configuration The CPU Configuration setup screen varies depending on the installed processor. Hyper-threading This item is used to enable or disable the processor’s Hyper-threading feature. Enabled for Windows XP and Linux (OS optimized for Hyper-threading Technology) and disabled for other OS (OS not optimized for Hyper-threading Technology).

  • Page 58: Sata Configuration

    BIOS 3.2.3 SATA Configuration It allows you to select the operation mode for SATA controller. SATA Controller(s) Enable or disable SATA devices. SATA Mode Selection The choice: Disable; IDE (Default), AHCI. IDE: Set the Serial ATA drives as Parallel ATA storage devices. AHCI: Allow the Serial ATA devices to use AHCI (Advanced Host Controller Interface).

  • Page 59: Intel Anti-Theft Technology Configuration

    BIOS 3.2.4 Intel Anti-Theft Technology Configuration Intel Anti-Theft Technology Enable or disable Intel® Anti-Theft Technology function in BIOS. Intel Anti-Theft Technology Recovery Set the number of times Recovery attempted will be allowed. Enter Intel AT Suspend Mode Enable or disable the request that platform enters AT suspend mode. - 53 -...

  • Page 60: Usb Configuration

    BIOS 3.2.5 USB Configuration Legacy USB Support Enable support for legacy USB. AUTO option disables legacy support if no USB devices are connected. The choice: Enabled (Default); Auto; Disabled EHCI Hand-off Allow you to enable support for operating systems without an EHCI hand-off feature.
  • Page 61 BIOS USB hardware delays and time-outs USB transfer time-out — The time-out value for control, bulk, and interrupt transfers. Default setting: 20 sec Device reset time-out — USB mass storage device start unit command time- out. Default setting: 20 sec Device power-up delay —...

  • Page 62: Super Io Configuration

    BIOS 3.2.6 Super IO Configuration You can use this item to set up or change the Super IO configuration for serial ports. Power On After Power Failure Specify what state to go to when power is re-applied after a power failure. - 56 -...
  • Page 63 BIOS Serial Port 1~2 Configuration Serial Port Use the Serial port option to enable or disable the serial port. The choice: Enabled, Disabled Change Settings Use the Change Settings option to change the serial port’s IO port address and interrupt address. The choice: Auto IO=3F8h;...

  • Page 64: H/W Monitor

    BIOS 3.2.7 H/W Monitor PC Health Status The hardware monitor menu shows the operating temperature and system voltages of CPU module. - 58 -...

  • Page 65: Conosole Redirection

    BIOS 3.2.8 Conosole Redirection Consoler Redirection Console Redirection Enable or Disable. - 59 -...

  • Page 66: Sandybridge Ppm Configuration

    BIOS 3.2.9 Sandybridge PPM Configuration EIST Enable/Disable Intel SpeedStep. CPU C3 Report Enable/Disable CPU C3(ACPI C2) report to OS. CPU C6 Report Enable/Disable CPU C6(ACPI C3) report to OS. CPU C7 Report Enable/Disable CPU C7(ACPI C3) report to OS. Long duration power limit Long duration power limit in Watts, 0 means use factory default.

  • Page 67: Chipset

    BIOS 3.3 Chipset This section allows you to configure and improve your system; also, set up some system features according to your preference. - 61 -...

  • Page 68: System Agent (Sa) Configuration

    BIOS 3.3.1 System Agent (SA) Configuration CHAP Device (B0:D7:F0) Enable or disable SA CHAP Device. Thermal Device (B0:D4 F0) Enable or disable SA Thermal Device. Enable NB CRID Enable or disable NB CRID WorkAround. - 62 -...
  • Page 69 BIOS Graphics Configuration Primary Display Select which of IGFX/PEG/PCI Graphics Devices should be Primary Display or select SG for Switchable Gfx. Internal Graphics Keep IGD enabled based on the option. GTT Size Select the GTT Size: 1MB, 2MB. Aperture Size Select the Aperture Size: 128MB, 256MB, 512MB.
  • Page 70 BIOS LCD Control Primary IGFX Boot Display Select the Video Device which will be activated during POST. This has no ef- fect if external graphics present. Secondary boot display selection will appear based on your selection. VGA modes will be supported only on primary display. LCD Panel Type Select LCD panel used by Internal Graphics Device by selecting the appropri- ate setup item: VBIOS Default, 640x480 LVDS ~ 2048x1536 LVDS.
  • Page 71 BIOS Backlight Control The choice: PWM Inverted (Default), PWM Normal, GMBus Inverted and GM- Bus Normal. The choice: VBIOS Default, Disabled and Level 1/2/3/4/5. Spread Spectrum clock Chip The default setting is Off. Other options are: Hardware: Spread is controlled by chip. Software: Spread is controlled by BIOS.
  • Page 72 BIOS DMI Configuration Control various DMI functions. DMI Vc1/Vcp/Vcm Control Enable or disable DMI Vc1/Vcp/Vcm. DMI Link ASPM Control Enable or disable the control of Active State Power Management on SA side of the DMI Link. The choice: Disabled, L0s, L1, L0sL1 DMI Extended Synch Control Enable or disable DMI Extended Synchronization.
  • Page 73 BIOS NB PCIe Configuration Configure NB PCIe Express Settings. PEG0 – Gen X Configure PEG0 B0:D1:F0 Gen1-Gen2. The choice: Auto, Gen1, Gen2 PEG1 – Gen X Configure PEG1 B0:D1:F1 Gen1-Gen2. The choice: Auto, Gen1, Gen2 PEG2 – Gen X Configure PEG2 B0:D1:F2 Gen1-Gen2. The choice: Auto, Gen1, Gen2 PEG3 –...
  • Page 74 BIOS PEG ASPM Control ASPM support for the PEG Device. This has no effect if PEG is not the currently active device. The choice: Disabled, Auto, ASPM L0s, ASPM L1, ASPM L0sL1 De-emphasis Control Configure the De-emphasis control on PEG. The choice: -6 dB, -3.5 dB Memory Configuration DIMM profile...
  • Page 75 BIOS Max TOLUD Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic control- ler. The choice: Dynamic, 1GB, 1.25 GB, 1.5 GB, 1.75 GB, 2GB, 2.25 GB, 2.5 GB, 2.75 GB, 3 GB, 3.25 GB NMode Support NMode Support Option.
  • Page 76 BIOS Memory Thermal Configuration Memory Thermal Configuration Options. Memory Thermal Management Enable or disable Memory Thermal Management. PECI Injected Temperature Enable or disable memory temperatures to be injected to the processor via PECI. EXTT# via TS-on-Board Enable or disable routing TS-on-Board’s ALERT# and THERM# to EXTTS# pins on the PCH.
  • Page 77 BIOS GT – Power Management Control RC6 (Render Standby) Check to enable render standby support. GT Overclocking Support Enable or disable GT Overclocking Support. - 71 -...

  • Page 78: Pch-Io Configuration

    BIOS 3.3.2 PCH-IO Configuration Wake on LAN Enable or disable Wake on LAN. Computer will start up simply by applying power to a connected external modem if WOR is enabled. Azalia Control detection of the Azalia device. Disabled = Azalia will be unconditionally disabled. Enabled = Azalia will be unconditionally enabled.
  • Page 79 BIOS USB Configuration EHCI1~2 Control the USB EHCI (USB2.0) functions. One EHCI controller must always be enabled. USB Ports Per-Port Disable Control Enable or disable each of the USB ports (0~9). - 73 -...
  • Page 80 BIOS PCI Express Configuration PCI Express Clock Gating Enable or disable PCI Express Clock Gating for each root port. DMI Link ASPM Control The control of Active State Power Management on both NB side and SB side of the DMI Link. DMI Link Extended Synch Control The control of Extended Synch on SB side of the DMI Link.
  • Page 81 BIOS PCI Express Root Port 1~3 PCI Express Root Port 1~3 Control the PCI Express Root Port. PEG1 – Gen X Configure PEG1 B0 :D1 :F1 Gen1-Gen2 The choice: Auto, Gen1, Gen2 ASPM Support Set the ASPM Level to Disabled, L0s, L1, L0sL1, Auto Force L0 - Force all links to L0 State AUTO - BIOS auto configuration DISABLE - Disable ASPM...
  • Page 82 BIOS Enable or disable PCI Express Unsupported Request Reporting. Enable or disable PCI Express Device Fatal Error Reporting. NFER Enable or disable PCI Express Device Non-Fatal Error Reporting. Enable or disable PCI Express Device Correctable Error Reporting. Enable or disable PCI Express Completion Timer TO. SEFE Enable or disable Root PCI Express System Error on Fatal Error.

  • Page 83: Boot Settings

    BIOS 3.4 Boot Settings The Boot menu items allow you to change the system boot options. Boot Configuration Bootup NumLock State This setting determines whether the Num Lock key should be activated at boot up. Quiet Boot This allows you to select the screen display when the system boots. Boot Option Priorities Select the boot sequence of the hard drives.

  • Page 84: Security

    BIOS 3.5 Security Administrator Password Use the Administrator Password to set or change a administrator password. ENTER PASSWORD Type the password, up to eight characters in length, and press <Enter>. The password typed now will clear any previously entered password from CMOS memory.
  • Page 85 BIOS changing any part of your system configuration. Additionally, when a password is enabled, you can also require the BIOS to request a password every time your system is rebooted. This would prevent unauthorized use of your computer. You can determine when the password is required within the BIOS Features Setup Menu and its Security option.

  • Page 86: Save & Exit

    BIOS 3.6 Save & Exit Save Changes and Reset Pressing <Enter> on this item and it asks for confirmation: Save configuration changes and exit setup? Pressing <OK> stores the selection made in the menus in CMOS - a special section of memory that stays on after you turn your system off. The next time you boot your computer, the BIOS configures your system according to the Setup selections stored in CMOS.

  • Page 87: Ami Bios Checkpoints

    BIOS 3.7 AMI BIOS Checkpoints 3.7.1 Checkpoint Ranges Status Code Range Description 0x01 – 0x0B SEC execution 0x0C – 0x0F SEC errors PEI execution up to and including memory 0x10 – 0x2F detection 0x30 – 0x4F PEI execution after memory detection 0x50 –...

  • Page 88: Standard Checkpoints

    BIOS 3.7.2 Standard Checkpoints SEC Phase Status Code Description 0x00 Not used Progress Codes 0x01 Power on. Reset type detection (soft/hard). 0x02 AP initialization before microcode loading 0x03 North Bridge initialization before microcode loading 0x04 South Bridge initialization before microcode loading 0x05 OEM initialization before microcode loading 0x06...
  • Page 89 BIOS PEI Phase Status Code Description Progress Codes 0x10 PEI Core is started 0x11 Pre-memory CPU initialization is started 0x12 Pre-memory CPU initialization (CPU module specific) 0x13 Pre-memory CPU initialization (CPU module specific) 0x14 Pre-memory CPU initialization (CPU module specific) 0x15 Pre-memory North Bridge initialization is started Pre-Memory North Bridge initialization (North Bridge...
  • Page 90 BIOS 0x32 CPU post-memory initialization is started 0x33 CPU post-memory initialization. Cache initialization CPU post-memory initialization. Application Processor(s) 0x34 (AP) initialization CPU post-memory initialization. Boot Strap Processor 0x35 (BSP) selection CPU post-memory initialization. System Management 0x36 Mode (SMM) initialization 0x37 Post-Memory North Bridge initialization is started Post-Memory North Bridge initialization (North Bridge 0x38...
  • Page 91 BIOS 0x55 Memory not installed 0x56 Invalid CPU type or Speed 0x57 CPU mismatch 0x58 CPU self test failed or possible CPU cache error CPU micro-code is not found or micro-code update is 0x59 failed 0x5A Internal CPU error 0x5B reset PPI is not available 0x5C-0x5F Reserved for future AMI error codes...
  • Page 92 BIOS 0xF9 Recovery capsule is not found 0xFA Invalid recovery capsule 0xFB – 0xFF Reserved for future AMI error codes DXE Phase Status Code Description 0x60 DXE Core is started 0x61 NVRAM initialization 0x62 Installation of the South Bridge Runtime Services 0x63 CPU DXE initialization is started 0x64...
  • Page 93 BIOS South Bridge DXE Initialization (South Bridge module 0x74 specific) South Bridge DXE Initialization (South Bridge module 0x75 specific) South Bridge DXE Initialization (South Bridge module 0x76 specific) South Bridge DXE Initialization (South Bridge module 0x77 specific) 0x78 ACPI module initialization 0x79 CSM initialization 0x7A –...
  • Page 94 BIOS 0xA4 SCSI initialization is started 0xA5 SCSI Reset 0xA6 SCSI Detect 0xA7 SCSI Enable 0xA8 Setup Verifying Password 0xA9 Start of Setup 0xAA Reserved for ASL (see ASL Status Codes section below) 0xAB Setup Input Wait 0xAC Reserved for ASL (see ASL Status Codes section below) 0xAD Ready To Boot event 0xAE...
  • Page 95 BIOS 0xD7 No Console Input Devices are found 0xD8 Invalid password 0xD9 Error loading Boot Option (LoadImage returned error) 0xDA Boot Option is failed (StartImage returned error) 0xDB Flash update is failed 0xDC Reset protocol is not available ACPI/ASL Checkpoints Status Code Description 0x01...

  • Page 96: Appendix

    Appendix Appendix Appendix - 90 -...

  • Page 97: Appendix A: I/O Port Address Map

    Appendix Appendix A: I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The following table lists the I/O port addresses used. Address Device Description 0x00000000-0x00000CF7 PCI bus 0x00000000-0x00000CF7...
  • Page 98 Appendix 0x000000BC-0x000000BD Programmable interrupt controller 0x000004D0-0x000004D1 Programmable interrupt controller 0x000004D0-0x000004D1 Motherboard resources 0x0000002E-0x0000002F Motherboard resources 0x0000004E-0x0000004F Motherboard resources 0x00000061-0x00000061 Motherboard resources 0x00000063-0x00000063 Motherboard resources 0x00000065-0x00000065 Motherboard resources 0x00000067-0x00000067 Motherboard resources 0x00000070-0x00000070 Motherboard resources 0x00000070-0x00000070 System CMOS/real time clock 0x00000080-0x00000080 Motherboard resources 0x00000080-0x00000080 Motherboard resources 0x00000092-0x00000092...
  • Page 99 Appendix 0x00000064-0x00000064 Standard 101/102-Key or Microsoft Natural PS/2 Keyboard 0x000003F8-0x000003FF Communications Port (COM1) 0x000002F8-0x000002FF Communications Port (COM2) 0x00000378-0x0000037F Printer Port (LPT1) 0x00000010-0x0000001F Motherboard resources 0x00000022-0x0000003F Motherboard resources 0x00000044-0x0000005F Motherboard resources 0x00000072-0x0000007F Motherboard resources 0x00000084-0x00000086 Motherboard resources 0x00000088-0x00000088 Motherboard resources 0x0000008C-0x0000008E Motherboard resources 0x00000090-0x0000009F Motherboard resources...

  • Page 100: Appendix B: Interrupt Request Lines (Irq)

    Appendix 0x000001CE-0x000001CF VgaSave 0x000002E8-0x000002EF VgaSave Appendix B: Interrupt Request Lines (IRQ) Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on board. Level Function IRQ 9 Microsoft ACPI-Compliant System IRQ 16 PCI standard PCI-to-PCI bridge...

  • Page 101: Appendix C: Bios Memory Map

    Appendix Appendix C: BIOS Memory Map Address Device Description 0xA0000-0xBFFFF PCI bus 0xA0000-0xBFFFF VgaSave 0xD0000-0xD3FFF PCI bus 0xD4000-0xD7FFF PCI bus 0xD8000-0xDBFFF PCI bus 0xDC000-0xDFFFF PCI bus 0xE0000-0xE3FFF PCI bus 0xE4000-0xE7FFF PCI bus 0x7DA00000-0xFEAFFFFF PCI bus 0x7DA00000-0xFEAFFFFF Motherboard resources 0xF7800000-0xF7BFFFFF Video Controller (VGA Compatible) 0xE0000000-0xEFFFFFFF Video Controller (VGA Compatible) 0xF7C2B000-0xF7C2B00F...
  • Page 102 Appendix 0xFED19000-0xFED19FFF Motherboard resources 0xF8000000-0xFBFFFFFF Motherboard resources 0xFED20000-0xFED3FFFF Motherboard resources 0xFED90000-0xFED93FFF Motherboard resources 0xFED45000-0xFED8FFFF Motherboard resources 0xFEE00000-0xFEEFFFFF Motherboard resources 0x20000000-0x201FFFFF System board 0x40000000-0x401FFFFF System board - 96 -...
