Form Factor
PICMG 1.0 Full size
SBC
I/O
PCI/ ISA/ USB/ IDE/
COM/ FDD/ SATA
Audio
HDA CODEC, Line-
in/ Line-out, MIC-in
(Optional)
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
Copyright
2008 All Rights Reserved.
®
HiCORE-i35Q
CPU
Supports Intel Core™ 2
Duo/ Conroe/ Conroe L/
Wolfdale-M/ Wolfdale-L
LGA775 Processor
LAN
RTL8111B 10/100/1000
Base-T Ethernet
PICMG 1.0 Full size SBC
Quick Installation Guide
40400350000P
- -
Version .0
Chipset
Intel Q35
ICH9
Video
CRT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology HiCORE-i35Q
Summary of Contents for Arbor Technology HiCORE-i35Q
- Page 1 HiCORE-i35Q PICMG 1.0 Full size SBC Quick Installation Guide Version .0 Form Factor Chipset Supports Intel Core™ 2 PICMG 1.0 Full size Intel Q35 Duo/ Conroe/ Conroe L/ ICH9 Wolfdale-M/ Wolfdale-L LGA775 Processor Video PCI/ ISA/ USB/ IDE/ RTL8111B 10/100/1000...
-
Page 2: Specifications
Specifications Form Factor PICMG .0 Full size SBC Supports socket LGA775 for Intel® Core™ 2 Duo Conroe/ Processor Conroe-L/ Wolfdale Chipset Intel® Q35 + ICH9 System Memory Two 240-pin DDRII DIMM Sockets up to 4GB SDRAM Integrated with Intel® Graphics Media Accelerator VGA Controller (GMA300) Ethernet... -
Page 3: Packing List
Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x HiCORE-i35Q PICMG 1.0 full size SBC 1 x CD-ROM x Quick Installation Guide 1 x COM port flat cable... -
Page 4: Jumpers/ Connectors Quick Reference
Jumpers/ Connectors Quick Reference Jumpers Connectors Label Description Label Description AT/ATX Power Mode Select ATX2V ATX 2V Connector PATA IDE Enable/ Disable JFRT Switches and Indicators Select CPUF CPU Fan Power Connector JBAT Clear CMOS Setup SYSF1, SYSF2 Fan Power Connector COM2 RS-232/422/485 JRS Mode Select... -
Page 5: Board Dimensions
Board Dimensions 121.92 26.76 71.98 27.3 4.98 5.93 13.72 22.99 25.15 14.57 10.01 100.34 121.92 Unit: mm - 5 -... - Page 6 Jumpers & Connectors ATX12V1 JFRT1 CPUF1 SYSF1 SYSF2 EATX1 JBAT1 18 19 20 21 22 EKB1 VGA1 LAN1 USB1 KBM1 - 6 -...
- Page 7 Jumpers Connectors AT1: AT/ATX Power Mode Select (11) ATX12V1: ATX +12V Connector (1) ATX2V supplies the CPU operation ATX +2V Connector type: 2.54mm pitch 1x2 pin header. (Vcore). Pin 1-2 Power Mode Select Desc. Desc. Short AT Mode ATX Mode +2V +2V Open...
- Page 8 SATA1~2: SATA Connectors (9)~ (10) EATX1: ATX Feature Connector (6) High speed transfer rates (300MB/s). Connector type: 2.54mm pitch 1x3-pin box wafer connector Description Description PS-ON 5V_SB TPM1: Trusted Platform Module Connector Connector type: 2.54mm pitch 2x10 pin header Desc. Desc.
- Page 9 IDE1: IDE Connector (15) USB2~6: USB Connector (18)~(22) Connector type: 2.54mm pitch 2x20 box header. Connector type: 2.54mm pitch 2x5 pin header. Pin Desc. Desc. USBD- USBD- Pin Description Pin Description USBD+ USBD+ IDE RESET 9 10 DATA7 DATA8 N/C (Key) DATA6 DATA9 IR1: Infrared Connector (23)
- Page 10 KBM1: Keyboard & Mouse Connector (27) The Installation Paths of CD Driver Mini-Din Keyboard & Mouse connector Driver Path Description CHIPSET \Chipset\Intel\INF 8. KB Data \ISA\ITE8888 MS Data \Ethernet\Realtek\8111B_WIN5640 \Graphics\Intel_2K_XP_32\43 KB Clock MS Clock VGA1: CRT Connector (28) Connector type: D-Sub 15-pin female. Desc.
