Form Factor
ETX® CPU Module
LAN
Realtek 8105E PCIe
10/100 Base-T Ethernet
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
ftp://ftp.arbor.com.tw/pub/manual
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://www.arbor.com.tw
E-mail: info@arbor.com.tw
Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright
All Rights Reserved.
®
EmETX-i2304
CPU
Soldered onboard
Intel® Atom™ E3800
Family CPU
Audio
Realtek AUDIO CODEC,
Mic-in/ Line-in/ Line-out
Quick Installation Guide
4041230400110P
- 1 -
ETX® CPU Module
Video
LVDS, Analog RGB
and DDI supported
I/O
PCI/ SATA/ USB/ IDE/
COM/ LPC/ PS/2/
Parallel Port
Version 1.1
Advertisement
Table of Contents
Related Manuals for Arbor Technology EmETX-i2304-E3825
Summary of Contents for Arbor Technology EmETX-i2304-E3825
- Page 1 EmETX-i2304 ETX® CPU Module Quick Installation Guide Version 1.1 Form Factor Video Soldered onboard LVDS, Analog RGB ETX® CPU Module Intel® Atom™ E3800 and DDI supported Family CPU Audio Realtek AUDIO CODEC, PCI/ SATA/ USB/ IDE/ Realtek 8105E PCIe Mic-in/ Line-in/ Line-out COM/ LPC/ PS/2/ 10/100 Base-T Ethernet Parallel Port...
- Page 2 1 x EmETX-i2304 ETX® CPU Module 1 x Driver CD 1 x Quick Installation Guide Ordering Information EmETX-i2304-E3825 Intel® Atom™ Processor E3825 ETX CPU module EmETX-i2304-E3845 Intel® Atom™ Processor E3845 ETX CPU module EmETX-i2304-E3826(BTO) Intel® Atom™ Processor E3826 ETX CPU module EmETX-i2304-E3827(BTO) Intel®...
- Page 3 The Installation Paths of CD Driver Windows 7 Driver Path \Audio\32bit_Win7_Win8_Win81_R275 AUDIO \Audio\64bit_Win7_Win8_Win81_R275 CHIPSET \Chipset\SetupChipset_10.0.13_PC Ethernet \Ethernet\Win7\Install_Win7_7085_05222014 \Graphics\WIN7_32\Intel_EMGD.WIN7_PC_Version_36_15_0_1073 Graphic \Graphics\WIN7_64\Intel_EMGD.WIN7_PC_Version_37_15_0_1073 Windows 8.1 Driver Path \Audio\32bit_Win7_Win8_Win81_R275 AUDIO \Audio\64bit_Win7_Win8_Win81_R275 CHIPSET \Chipset\SetupChipset_10.0.13_PC Ethernet \Ethernet\Win8_8.1\Install_Win8_8.1_8031_05222014 \Graphics\WIN8_32\15.33.22.3621 Graphic \Graphics\WIN8_64\15.33.22.64.3621 \TXE\Installers - 3 -...
-
Page 4: Specifications
Specifications Form Factor ETX® CPU Module Intel® Atom™ Processor E3825 dual-core 1.33GHz or E3845 quad-core 1.91GHz Intel® Atom™ Processor E3826 dual-core 1.46GHz or E3827 dual-core 1.75GHz (BTO) 1 x 204-pin SO-DIMM socket, up to 8GB DDR3L Memory 1333 MT/s SDRAM Graphics Chipset SoC Integrated Intel®... - Page 5 Board Dimension/ Connector Location Top View SATA1 SO-DIMM SATA2 LPC1 Unit:mm Bottom View IrDA PCI bus ETX3 ETX1 Serial Ports Parallel Port Audio Floppy Keyboard Mouse ETX4 ETX2 ISA bus SMbus Miscellaneous DDI1 - 5 -...
- Page 6 SATA1, SATA2 Connectors (Top side) Description LPC1 Connector (Top side, optional) Connector type: FPC12-14P-P0.5 (Hirose) Pin Desc. Pin Desc. LPC_RST# GND3 LPC_CLK(33M) GND4 GND1 GND5 LFRAME# VCC3(1) SER_IRQ VCC3(2) DDI1 Connector (Bottom side) Connector type: FH12-30S-0.5SH (Hirose) Description Description TXP3 +5VS TXN3 +5VS...
- Page 7 ETX1 Connector ETX2 Connector A1 GND GND A2 B1 GND GND B2 A3 PCICLK3 PCICLK4 A4 B3 SD14 SD15 B4 A5 GND GND A6 B5 SD13 MASTER# B6 A7 PCICLK1 PCICLK2 A8 B7 SD12 DREQ7 B8 A9 REQ#3 GNT#3 A10 B9 SD11 DACK#7 B10 A11 GNT#2...
- Page 8 ETX3 Connector ETX4 Connector C1 GND GND C2 D1 GND GND D2 C3 R B C4 D3 5V_SB PWGIN D4 C5 HSY G C6 D5 PS_ON SPEAKER D6 C7 VSY Analog RGB_DDC_CLK C8 D7 PWERBTN# BATT D8 C9 DETECT#(NC) Analog RGB_DDC_ATA C10 D9 KBINH (N/C) LILED D10 C11 TX2CLK#...
