Form Factor
Qseven
CPU Module
®
LAN
Intel® i210IT PCIe GbE
controller
♦ Technical Support
If you have any technical difficulties, please consult the user's manual first at:
http://www.arbor-technology.com
Please do not hesitate to call or e-mail our customer service when you still can not
find out the answer.
http://www.arbor-technology.com
E-mail: info@arbor.com.tw
Declaration of Conformity
FCC Class A
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions : (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
Copyright
All Rights Reserved.
®
EmQ-i2401
CPU
Intel® Celeron® N3350/
Pentium® N4200 Processor
Audio
HD Link
- 1 -
Qseven
R2.0 CPU Module
®
Quick Installation Guide
Video
Dual-Channel 24-bit LVDS/
DDI
I/O
USB2.0/ USB SuperSpeed/
SATA/ PCIex1/ SDIO/ I2C
Version 1.1
4041240100110P
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Arbor Technology EmQ-i2401
Summary of Contents for Arbor Technology EmQ-i2401
- Page 1 EmQ-i2401 Qseven R2.0 CPU Module ® Quick Installation Guide Version 1.1 Form Factor Video Qseven CPU Module Intel® Celeron® N3350/ Dual-Channel 24-bit LVDS/ ® Pentium® N4200 Processor Audio Intel® i210IT PCIe GbE HD Link USB2.0/ USB SuperSpeed/ controller SATA/ PCIex1/ SDIO/ I2C ♦...
-
Page 2: Packing List
Packing List Before starting with the installation, make sure the following items are shipped: 1 x EmQ-i2401 Qseven CPU Module ® 1 x Quick Installation Guide Ordering Information ® Intel Pentium ® N4200 Qseven R2.0 CPU module w/ 4G memory... -
Page 3: Specifications
Specifications Form Factor Qseven CPU Module ® Soldered onboard Intel Celeron® N3350 2.4GHz processor/ Intel Pentium® N4200 2.5GHz processor Soldered onboard 4GB DDR3L SDRAM, upgradable to 8GB System Memory BIOS AMI BIOS, UEFI Code 4 x USB 2.0 ports 2 x USB 3.0 SuperSpeed ports Expansion Bus 4 x PCIex1 lanes, I2C Interface, SDIO 2 x Serial ATA ports... -
Page 4: Driver Installation Note
Driver Installation Note The CPU module supports Windows 10. To install the drivers, please visit our website at www.arbor-technology.com and download the driver pack from the product page. If you need driver DVD, please contact your ARBOR sales repre- sentative. Windows 10 (64-bit) Driver Path... -
Page 5: Board Dimensions
Board Dimensions - 5 -... -
Page 6: Heat Spreader Installation
Heat Spreader Installation To install the heat spreader: See the illustration below. Mount the heat spreader to the board. Fix the heat spreader in place with fours screws. - 6 -... -
Page 7: Connector Pin Assignment
Connector Pin Assignment Pin Signal Pin Signal Pin Signal Pin Signal Q7_AZ_SDATA_IN I2C_CLK0 LAN1_MDI3- LAN1_MDI2- I2C_DATA0 Q7_AZ_SDATA_OUT LAN1_MDI3+ LAN1_MDI2+ THRM# WDTRIG# THRMTRIP# WDOUT(N/C) LAN_LINK100# LAN_LINK_1000# LAN1_MDI1- LAN1_MDI0- USB3TXN0 USB3_RXN0 LAN1_MDI1+ LAN1_MDI0+ USB3TXP0 USB3_RXP0 LED_LINK# LAN_ACT# USB_6_7_OC# (N/C) USB_4_5_OC#(N/C) SLP_S4# GBE_CTREF (N/C) USB3TXN1 USB3_RXN1 WAKE#... - Page 8 Pin Signal Pin Signal Pin Signal Pin Signal 131 Q7_DDI0_TXP3 132 RSVD (N/C) 197 GND 198 GND 133 Q7_DDI0_TXN3 134 RSVD (N/C) 199 Q7_SPI_MOSI 200 Q7_SPI_CS#0 135 GND 136 GND 201 Q7_SPI_MISO 202 Q7_SPI_CS#1 137 Q7_DDI0_TXP1 138 DDI0_AUXP 203 Q7_SPI_CLK 204 MFG_NC4 (N/C) 139 Q7_DDI0_TXN1 140 DDI0_AUXN...
