- Page 1 EmCORE-i90U2 3.5" Compact Board Quick Installation Guide Version 1.0 Form Factor Video 3.5" Compact Board Soldered onboard Dual Channel 24-bit LVDS/ HDMI/ DisplayPort ® Generation Intel Core™ Processor Audio SATA/ USB 3.0/ USB 2.0/ Realtek ALC269 HD Audio 1 x Intel® i219LM PCIe PHY SIM/ COM/ M.2 B-Key,...
-
Page 2: Packing List
Packing List Before starting with the installation, make sure the following items are shipped: 1 x EmCORE-i90U2 3.5" Compact Board w/ Cooler 1 x Quick Installation Guide If any of the aforelisted items is damaged or missing, contact your vendor immediately. - Page 3 Driver Installation (6.8A) To install the drivers, please visit our website at www.arbor-technology.com and download the driver pack from the product page. The driver path is listed as below: Driver Path Chipset \EmETXe-i90x0\Chipset Graphic \EmETXe-i90x0\Graphic\win64 Audio \EmETXe-i90x0\Audio\Win10_Win8.1_Win8_Win7_WHQLx64 Ethernet \EmETXe-i90x0\Ethernet \EmETXe-i90x0\ME \EmETXe-i90x0\RST\SetupRST - 3 -...
-
Page 4: Board Dimensions
Board Dimensions 145.98 (32) 3.2x6.3 142.8 (19.81) 142.8 (29.4) 134.01 40.7 19.5x4=78 21.4 2.99 40.7 19.5x3=58.5 Unit: mm - 4 -... -
Page 5: Specifications
Specifications Form Factor 3.5" Compact Board Soldered onboard 7th Gen. Intel Core™ Processor i7-7600U 2.8GHz/ ® 3.4GHz, i5-7300U 2.6GHz/2.8GHz, i3-7100U 2.4GHz 2 x DDR4 SO-DIMM sockets, supporting 2133/1866MHz SDRAM up to Memory 32GB BIOS AMI UEFI BIOS Support TPM 1.2 SLB9660 & 2.0 SLB9665 function onboard (OEM request) Watchdog Timer 1~255 levels reset... - Page 6 Jumpers & Connectors Quick Reference Jumpers Jumper Description ➊ Power mode selection ➋ LCD inverter voltage selection JINV1 ➌ LCD panel voltage selection JVLCD1 Connectors Connector Description ① CPU fan connector FAN1 ② M.2 E-Key socket WIFI1 ③ M.2 B-Key socket SSD1 ④~⑦...
- Page 7 Jumper & Connector Locations Board Top PWROUT1 AUDIO1 SATA1 SATA1 SATA1 FAN1 JINV1 LPC1 LPC1 LPC1 WIFI1 USB5 USB6 SSD1 INV1 COM3, 4 JVLCD1 JVLCD1 LVDS1 LVDS1 LVDS1 JFRT1 JFRT1 DIO1 DIO1 JFRT1 COM1, 2 DIO1 PWR2 SMB1 POE1 POE1 POE2 POE2 POE4...
- Page 8 Jumpers Connectors ① ➊ FAN1: CPU Fan Connector SW1: Power mode selection Connector type: 1.25mm pitch 1x3-pin wafer Caution: When setting this jumper, make sure the connector. motherboard is disconnected from the power. Description Mode Description Input & LVDS inverter power selec- Pin 1 tion 15~36V power input...
- Page 9 ⑧ ⑰ SMB1: SMBus Connector PADP1: 9-36V DC power input connector Connector type: 1.25mm pitch 1x3-pin wafer connector (Option 1) Connector type: DC power jack connector. Description Description SM_CLK DC_IN SM_DATA DC_IN ⑨ BAT1: Battery connector Caution: PADP1 and PWR2 cannot be Connector type: 1.25mm pitch 1x2 pin wafer used simultaneously.
- Page 10 AUDIO1: Audio connector INV1: LCD inverter connector Connector type: 1.25mm pitch 1x6-pin box wafer Connector type: 1.25mm pitch 1x13-pin wafer connector connector Pin Description Pin Description LVDS1_INV LINL LVDS1_INV LINR LVDS1_BKLT_EN LIN_JD LVDS1_BKLT_CTRL AGND MICL MICR MIC_JD LVDS1: LVDS LCD panel connector AGND Connector type: ACES 1.25mm 87209-3040-06 LOUT-L...
- Page 11 CN2: 1x PCIe x4 or 4 x PCIe x1 FPC Connector (OEM Request) Connector type: FFC/FPC 1x 40P-pin connector Pin Description Pin Description 21 PCIE_TXP12 PCIE_TXN9 22 GND PCIE_TXP9 23 PCIE_RXN12 24 PCIE_RXP12 PCIE_RXN9 25 GND PCIE_RXP9 26 CLKOUT_PCIE_N4 27 CLKOUT_PCIE_P4 PCIE_TXN10 28 GND PCIE_TXP10...
