Summary of Contents for AUMA TR-PAFE Series
- Page 1 Parking frame TR-PAFEx for use in potentially explosive atmospheres Operation instructions Assembly...
-
Page 2: Table Of Contents
TR-PAFEx Table of contents Read operation instructions first. Observe safety instructions. These operation instructions are part of the product. Store operation instructions during product life. Pass on instructions to any subsequent user or owner of the product. Target group: This document contains information for assembly, commissioning and maintenance staff. Table of contents Page Safety instructions......................... -
Page 3: Safety Instructions
TR-PAFEx Safety instructions Safety instructions 1.1. Basic information on safety After assembly, this means after each retrofitting or after any mounting or dismantling of components, the commissioning settings must be verified in compliance with the operation instructions. Prior to working on the devices, persons working on the actuator and the parking Safety instructions/ frame must be familiar with the safety and warning instructions of these operation Warnings... - Page 4 TR-PAFEx Safety instructions Indicates an imminently hazardous situation with a high level of risk. Failure to observe this warning results in death or serious injury. Indicates a potentially hazardous situation with a medium level of risk. Failure to observe this warning could result in death or serious injury. Indicates a potentially hazardous situation with a low level of risk.
-
Page 5: Identification
TR-PAFEx Identification Identification 2.1. Name plate Figure 1: Arrangement of name plates Parking frame name plate Approval plate Ex marking Parking frame name plate Figure 2: Parking frame name plate (example) Name of manufacturer Address of manufacturer Type designation Order number Serial number Wiring diagram number Permissible ambient temperature... - Page 6 Please always state this number for any product inquiries. On the Internet at http://www.auma.com > Service & Support >myAUMA, we offer a service allowing authorised users to download order-related documents such as wiring diagrams and technical data (both in German and English), inspection certificate and the operation instructions when entering the order number.
-
Page 7: Short Description
Internal number for unambiguous product identification Data Matrix code When registered as authorised user, you may use our AUMA Assistant App to scan the Data Matrix code and directly access the order-related product documents without having to enter order number or serial number. -
Page 8: Assembly
TR-PAFEx Assembly Assembly 3.1. Basic information on assembly Please always heed safety and warning instructions of these operation instructions and the operation instructions pertaining to the actuator throughout all steps. Observe screw and screw plug tightening torques. Table 3: Screw and screw plug tightening torques Threads Tightening torque [Nm] Tightening torque [Nm]... -
Page 9: Mount Electrical Connection Onto Parking Frame
TR-PAFEx Assembly In case of a fault, electric shock due to presence of hazardous voltage if the PE conductor is NOT connected! Risk of death or serious injury! Connect all protective earth conductors. Power the device only once the protective earth conductor has been connected. Connect equipotential earth bonding at external earth connection for equipoten- tial compensation (U-bracket with symbol Figure 7: External earth connection... -
Page 10: Remove Cover From Parking Frame
TR-PAFEx Assembly 3.3.1. Remove cover from parking frame Figure 8: Remove cover Unscrew screws [2] from cover [1]. Remove cover [1]. 3.3.2. Mount KT-Ex e/KM-Ex e electrical connection to parking frame Figure 9: Example of mounting KT-Ex e electrical connection... -
Page 11: Mount Kt-Ex D /Km-Ex D Electrical Connection To Parking Frame
TR-PAFEx Assembly Remove electrical connection from actuator. Information: Refer to operation instructions pertaining to the actuator, <Disconnection from the mains with KT/KM electrical connection> chapter. Electric shock due to presence of hazardous voltage! Death or serious injury. Disconnect device from the mains before opening. Ignition of potentially explosive atmospheres caused by sparks! Risk of death or serious injury! Before opening the flameproof enclosure, ensure absence of gas and voltage. - Page 12 TR-PAFEx Assembly Remove electrical connection from actuator. Information: Refer to operation instructions pertaining to the actuator, <Disconnection from the mains with KT/KM electrical connection> chapter. Electric shock due to presence of hazardous voltage! Death or serious injury. Disconnect device from the mains before opening. Ignition of potentially explosive atmospheres caused by sparks! Risk of death or serious injury! Before opening the flameproof enclosure, ensure absence of gas and voltage.
-
Page 13: Spare Parts
TR-PAFEx Spare parts Spare parts 4.1. TR-PAFEx parking frame... - Page 14 Spare parts Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used. Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary from actual delivery.
-
Page 15: Index
TR-PAFEx Index Index Ambient temperature Application range Approval plate Assembly Assistant App AUMA Assistant App Data Matrix code Enclosure protection Ex certificate Explosion protection Explosion protection marking Identification Inspection certificate Marking for explosion protec- tion Name plate Order number 5, 6... - Page 16 AUMA Riester GmbH & Co. KG P.O. Box 1362 DE 79373 Muellheim Tel +49 7631 809 - 0 Fax +49 7631 809 - 1250 info@auma.com www.auma.com Y009.440/003/en/2.21 For detailed information on AUMA products, refer to the Internet: www.auma.com...
