Controller Layout; Lan Setup - Rath JANUS SmartView Installation & Operation Manual

Controller Layout

Installation & Wiring Diagrams
Wiring with Ethernet Extenders (2100-SVE) (Must be Supplied by RATH
Machine Room
Machine Room
Ethernet
Patch
Cable CAT 5E
2100-SVE
2100-SVE
Main Extender
(PoE Extender Main)
(PoE Extender Main)
RP7700104S
RP7700104S
(Power Supply/UPS/Battery)
(Power Supply/UPS/ Battery)
Single Pair
Single Pair
Wire to pins 1 and 2 of the RJ45 connector.
Wire to pins 1 and 2 of the RJ45 connector
Extends power and communication up to 1,600 feet.
Extends power and communication up to 1,600 feet
Notes:
• 2-wire from main Extender to remote Extender
Outbound
• Ethernet Patch Cable from communication source to main
Outbound
Communication
Communication
Source Source
Ethernet Extender
• Ethernet Patch Cable from remote Ethernet Extender to
SmartView Controller
When powering via PoE battery backup can be done remotely. When powering via PoE battery backup can be done remotely. Battery backup can be done remotely.
Elevator Car
Elevator Car
COP
COP
RATH Components SmartView Components
YES
YES
)
®
2100-SVCB
Camera 2100-SVCB
Camera
(5v, 0.5A)
(5V, 0.5A)
2100-SVD
Display
2100-SVD
YES NO Ethernet
USB
Display
(5v, 0.59A) (5V, 0.59A)
SOM
2100-SVC
Controller (PoE Powered)
NO
NO
D PWR
PWR
CAT5E
CAT 5E
2100-SVE
2100-SVE
Ethernet
Remote Extender
(PoE Extender Remote)
(PoE Extender Remote)
Patch
Cable
Page 5
