PMFoundations ER-808 Bass Module Assembly Manual
Hide thumbs
Also See for ER-808 Bass Module:
- Assembly manual (16 pages) ,
- User manual (5 pages) ,
- Assembly manual (6 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for PMFoundations ER-808 Bass Module
Summary of Contents for PMFoundations ER-808 Bass Module
- Page 1 ER-808 – Assembly Guide _____________________________________________________________________________________ PM Foundations ER-808 v1.4 Bass Module _____________________________________________________________________________________ Page 1 of 6...
- Page 2 ER-808 – Assembly Guide _____________________________________________________________________________________ Resistors Arrange the resistors by value on the workbench in the same order as listed in the BOM and install each numbered part for that value before moving onto the next. Only install the 390k resistor if you want RESONANT BASS. Install the resistors on the TOP of the board.
- Page 3 ER-808 – Assembly Guide _____________________________________________________________________________________ Electrolytic capacitors Install on the TOP. Make sure you orient correctly. The longer lead and/or the lead marked with a + needs to be inserted into the hole that has the “+” marking near it. Leads marked with “-“ go in the board hole WITHOUT the “+”.
- Page 4 ER-808 – Assembly Guide _____________________________________________________________________________________ _____________________________________________________________________________________ Page 4 of 6...
- Page 5 ER-808 – Assembly Guide _____________________________________________________________________________________ Testing Install the ICs. Plug the module into the Bus PCB. Connect the L and R outputs of the Trigger/Output module to an amplifier or other listening device in your rack. Power on. Set Bass LEVEL to full CW, DECAY to min CCW, TONE to max CW. Press the button to light and then build a pattern of steps (see User Guide).
- Page 6 ER-808 – Assembly Guide _____________________________________________________________________________________ Check the controls for Decay, Tone and Level. _____________________________________________________________________________________ Page 6 of 6...
