- Page 1 ER-808 – User Guide _____________________________________________________________________________________ PM Foundations ER-808 v1.4 User Guide _____________________________________________________________________________________ Page 1 of 5...
- Page 2 This is PMF’s tribute to the Roland TR-808, as a Eurorack-compatible module composed of a panel and a set of build-it-yourself PCBs. The ER-808 is driven by a PIC microcontroller which is pre-programmed and included with the PCB set. 2. Touch panel vs Button panel There are two versions of this project.
- Page 3 ER-808 – User Guide _____________________________________________________________________________________ 7. Mode button. Track mode (LED is ON): Enables selection of step buttons representing saved patterns, e.g. 1,2,2,3 to build a chain of patterns. The chain keeps on getting built as each step is pressed. The chain floats locally until saved.
- Page 4 To reduce or eliminate noise you can connect the outputs of the ER-808 to a VCA and use the Trigger Out pulse applied to each step to open the VCA either directly or through an external Envelope Generator. This patch creates a noise-gate for the ER-808 which keeps it silent except when a drum sound is programmed on a step.
- Page 5 ER-808 – User Guide _____________________________________________________________________________________ //1 rock b //2 bossa nova a //3 bossa nova b //4 mambo a //5 mambo b //6 samba a //7 samba b //8 bm 1 a //9 bm 1 b //10bm 2 a //11bm 2 b...
