5.5"
3"
*Drawing not to Scale. All Measurements are Approximate
Luxier USA
Single Handle Bathroom Lavatory Faucet
Model Number:
BSH05-SB
(Brushed Nickel)
BSH05-SC
(Chrome)
BSH05-SM
(Matte Black)
BSH05-SO
(Oil Rubbed Bronze)
1.56"
1.81"
Features:
- Brass Construction
- Single Hole Installation
- Drip Free Ceramic Cartridge
- Maximum flow rate 1.2 gpm at 60 psi
- Complies with:
NSF 61-9
ASME A112.18.1 / CSA B125.1
IAPMO / UPC / cUPC
CA AB-1953
ADA
11.69"
5"
1 3/8" Hole Size
Approx. 30" water supply hose
3/8" compression tting
1
3.5"
Max. Deck Thickness 2"
BSH05S Rev. C1 05/2021
Advertisement
Related Manuals for Luxier BSH05-SB
Summary of Contents for Luxier BSH05-SB
- Page 1 Single Handle Bathroom Lavatory Faucet Model Number: Features: BSH05-SB - Brass Construction (Brushed Nickel) BSH05-SC - Single Hole Installation (Chrome) BSH05-SM - Drip Free Ceramic Cartridge (Matte Black) BSH05-SO - Maximum flow rate 1.2 gpm at 60 psi (Oil Rubbed Bronze)
- Page 2 Should a malfunction occur within the warranty period, Luxier USA will, as its option, (1) repair or replace the defective part(s) or product at no charge; (2) issue a refund of the purchase price paid for the product (Valid within 30 days from the date of purchase);...
- Page 3 • When using spray cleaners, spray fi rst onto a soft cloth or sponge. Never spray directly onto the faucet as droplets can enter openings and gaps and cause damage. • After cleaning, rinse thoroughly with clean water to remove any cleaner residue. Luxier USA BSH05S Rev. C1 05/2021...
- Page 4 04. Cap 05. Bonnet 06. Cartridge 07. Body 08. Aerator 09. Water Supply Hoses 10. Base 11. Screws 12. Rubber Washer 13. Rubber Gasket 14. Metal Washer 15. Locking Nut 16. Pop Up Drain Assembly Luxier USA BSH05S Rev. C1 05/2021...
