3.3"
1.8"
2.2"
1 1/2" Hole Size
2.6"
Hose Length 25"
Single Handle Kitchen Faucet with Pull Down Sprayer
Model Number:
KTS11-TB
KTS11-TC
KTS11-TO
16"
6.6"
3.1"
3/8" Compression Fitting
1
Features:
- Brass and Zinc Alloy Construction
- Single Hole Installation
- Drip Free Ceramic Cartridge
- Maximum flow rate 2.2 gpm at 60 psi
- Pull Down 2 Stage Sprayer Head
- Complies with:
NSF 61-9
ANSI / ASME A112.18.1
cUPC
IAPMO / UPC
CA AB-1953
2.1"
1.02"
8 "
2.2"
* Drawing not to scale. All Measurements are pproximate.
12°
8"
Max. Deck Thickness 2"
Luxier Rev.1.2 09/2016
Advertisement
Related Manuals for Luxier KTS11-TB
Summary of Contents for Luxier KTS11-TB
- Page 1 16” 2.1” 1.02” 3.3” 1.8” 12° 6.6” 8” 8 ” 3.1” 2.2” 1 1/2” Hole Size Max. Deck Thickness 2” 2.2” 2.6” Hose Length 25” 3/8” Compression Fitting * Drawing not to scale. All Measurements are pproximate. Luxier Rev.1.2 09/2016...
- Page 2 (2) issue a refund of the purchase price paid for the product (Valid within 30 days from the date of purchase); or (3) issue a credit to be applied against the purchase of a new Luxier product. Shipping/delivery charges may apply and are in Luxier USA’s sole discretion.
- Page 3 • When installing your new faucet, first hand tighten the water supply hoses then use a wrench to give the compression nuts an additional (1/4) turn. Do not over tighten the compression nuts as it will reduce the integrity of the sealed connection. Luxier Rev.1.2 09/2016...
- Page 4 1 minute and check 12. Retainer for leaks. Reattach the spray head. 13. Pull Out Hose 14. Spout 15. O Ring 16. Locking Ring 17. Body 18. Flange 19. EVA Washer 20. Shank 21. Steel Washer Luxier Rev.1.2 09/2016...
