14.2"
2"
Luxier USA
Single Handle Vessel Sink Faucet
Model Number:
Factory Ref. Number:
1.73"
2.2"
1 3/8" Hole Size
3/8" compression tting
Features:
BSH04-TB
- Solid Brass Waterway
BSH04-TC
- Single Hole Installation
BSH04-TO
- Drip Free Ceramic Cartridge
- Maximum flow rate 1.2 gpm at 60 psi
- Complies with:
UF56503
NSF 61-9
UF56500
ANSI / ASME A112.18.1
UF56505
IAPMO / UPC / cUPC
CA AB-1953
CEC
5.2"
3.4"
1
14.2"
8.4"
Max. Deck Thickness 1.75"
*All Measurements are Approximate
BSH04T Rev. B 06/2018
Advertisement
Table of Contents
Related Manuals for Luxier BSH04-T
Summary of Contents for Luxier BSH04-T
- Page 1 ANSI / ASME A112.18.1 UF56505 IAPMO / UPC / cUPC CA AB-1953 5.2” 1.73” 3.4” 14.2” 14.2” 8.4” 2.2” Max. Deck Thickness 1.75” 2” 1 3/8” Hole Size 3/8” compression tting *All Measurements are Approximate Luxier USA BSH04T Rev. B 06/2018...
- Page 2 (2) issue a refund of the purchase price paid for the product (Valid within 30 days from the date of purchase); or (3) issue a credit to be applied against the purchase of a new Luxier product. Shipping/delivery charges may apply and are in Luxier USA’s sole discretion.
- Page 3 • When using spray cleaners, spray fi rst onto a soft cloth or sponge. Never spray directly onto the faucet as droplets can enter openings and gaps and cause damage. • After cleaning, rinse thoroughly with clean water to remove any cleaner residue. Luxier USA BSH04T Rev. B 06/2018...
- Page 4 1 minute to clear any debris in the plumbing system. Attach the aerator. Flange EVA Washer Shank (RP812B73) Rubber Washer (RP812A55) Metal Washer (RP812A74) Mounting Nut (RP812A03) Screws (RP812A77) Guide (RP812A48) Water Supply Hose Luxier USA BSH04T Rev. B 06/2018...
