5.5"
3"
*Drawing not to Scale. All Measurements are Approximate
Luxier USA
Single Handle Bathroom Lavatory Faucet
Model Number:
BSH05-SB
(Brushed Nickel)
BSH05-SC
(Chrome)
BSH05-SO
(Oil Rubbed Bronze)
1.56"
1.81"
Features:
- Brass Construction
- Single Hole Installation
- Drip Free Ceramic Cartridge
- NEOPERL
®
at 60 psi
- Complies with:
NSF 61-9
ASME A112.18.1 / CSA B125.1
IAPMO / UPC / cUPC
CA AB-1953
ADA
11.69"
2.875"
5"
1 3/8" Hole Size
Approx. 30" water supply hose
3/8" compression tting
1
aerator 1.2 gpm maximum
3.5"
Max. Deck Thickness 2"
BSH05S Rev. B 07/2018
