3.15"
1.97"
Luxier USA
Widespread Two Handles Lavatory Faucet
WSP11-TB
(Brushed Nickel)
WSP11-TC
(Chrome)
WSP11-TG
(Brushed Gold)
WSP11-TM
(Matte Black)
WSP11-TO
(Oil Rubbed Bronze)
Recommend 10" - 12" spread
1.89"
Features:
- Three Hole Installation
- Drip Free 1/4 Turn Ceramic Cartridge
- Maximum flow rate 1.2 gpm at 60 psi
- Complies with:
ADA
NSF 61-9
ANSI / ASME A112.18.1
IAPMO / UPC / cUPC
CA AB-1953
CEC
8.03"
1.375" Hole Size
Approx. 22" long hose with 3/8" compression ttings
* Drawing not to scale. All Measurements are approximate*
1
4.92"
5.08"
Max. Deck Thickness 1.5"
WSP11 Rev. B 03/2021
