7.6"
Luxier USA
Single Handle Lavatory Faucet
Model Number:
BSH14-SC
(Chrome)
BSH14-SM
(Matte Black)
BSH14-SO
(Oil Rubbed Bronze)
BSH14-SS
(Spot Resistant Brushed Nickel)
2.4"
1.9"
1.375" Hole Size
Approx. 25" long hose with 3/8" compression ttings
Features:
- Single Hole (Right Hand) Installation
- 1/4 Turn Drip Free Ceramic Cartridge
- Maximum Flow Rate 1.2 gpm at 60 psi
- 2 Stage Sprayer Head
- Complies with:
NSF 61-9
ANSI / ASME A112.18.1
cUPC
IAPMO / UPC
CA AB-1953
ADA
6.5"
5.4"
* Drawing not to scale. All Measurements are approximate*
1
Max. Deck Thickness 2.25"
BSH14-S Rev. 1 6/2020
Advertisement
Related Manuals for Luxier BSH14-SC
Summary of Contents for Luxier BSH14-SC
- Page 1 Single Handle Lavatory Faucet Model Number: Features: BSH14-SC - Single Hole (Right Hand) Installation (Chrome) - 1/4 Turn Drip Free Ceramic Cartridge BSH14-SM (Matte Black) - Maximum Flow Rate 1.2 gpm at 60 psi BSH14-SO (Oil Rubbed Bronze) - 2 Stage Sprayer Head...
- Page 2 Should a malfunction occur within the warranty period, Luxier USA will, as its option, (1) repair or replace the defective part(s) or product at no charge; (2) issue a refund of the purchase price paid for the product (Valid within 30 days from the date of purchase);...
- Page 3 • When using spray cleaners, spray fi rst onto a soft cloth or sponge. Never spray directly onto the faucet as droplets can enter openings and gaps and cause damage. • After cleaning, rinse thoroughly with clean water to remove any cleaner residue. BSH14-S Rev. 1 6/2020 Luxier USA...
- Page 4 06. Cartridge 07. Body 08. Aerator 09. Shank 10. Flange 11. Rubber Washer 12. Washer 13. Metal Washer 14. Locking Nut 15. Screws (x3) 16. Water Supply Hoses (non-removable) 17. Pop Up Drain Assembly BSH14-S Rev. 1 6/2020 Luxier USA...
