1.5"
Luxir USA
Widespread Two Handles Lavatory Faucet
WSP03-TB
WSP03-TC
WSP03-TO
Features:
- Three Hole Installation
- Solid Brass Construction
- Drip Free 1/4 Turn Ceramic Cartridge
- Maximum flow rate 1.2 gpm at 60 psi
- Complies with:
8" ~ 12"
2"
1.5"
(Brushed Nickel)
(Chrome)
(Oil Rubbed Bronze)
NSF 61-9
ANSI / ASME A112.18.1
IAPMO / UPC / cUPC
CA AB-1953
CEC
8"
2.6"
3"
1.75"
1.25" Hole Size
1" Hole Size
1/2"
Connection
* Drawing not to scale. All Measurements are approximate*
1
5.1"
6.2"
Max. Deck Thickness 1"
WSP03 Rev. D 04/2020
Advertisement
Table of Contents
Related Manuals for Luxier WSP03-T
Summary of Contents for Luxier WSP03-T
- Page 1 Widespread Two Handles Lavatory Faucet WSP03-TB (Brushed Nickel) WSP03-TC (Chrome) WSP03-TO (Oil Rubbed Bronze) Features: - Three Hole Installation - Solid Brass Construction - Drip Free 1/4 Turn Ceramic Cartridge - Maximum flow rate 1.2 gpm at 60 psi - Complies with: NSF 61-9 ANSI / ASME A112.18.1 IAPMO / UPC / cUPC...
- Page 2 Should a malfunction occur within the warranty period, Luxier USA will, as its option, (1) repair or replace the defective part(s) or product at no charge; (2) issue a refund of the purchase price paid for the product (Valid within 30 days from the date of purchase);...
- Page 3 Important Points • This installation guide is subject to change without notice, please contact us to request the most updated version of this installation guide. • This is a general installation guideline, actual installation may vary. Consult a professional if necessary.
- Page 4 Installation A. Shut off water supply at the valves. B. Place spout with flange through the center C. Slide hot and cold water handle / valve Remove old faucet and clean the mounting mounting hole on the mounting surface. through mounting holes. Make sure the surface for installation of new faucet.
