User Guide
Vico MT 727, Vico MT 1027, Vico MT 1527
Multi-touch Panel with CODESYS HMI
Web Terminal
E 863 GB
01/10/2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Vico MT 727 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kendrion Vico MT 727

  • Page 1 User Guide Vico MT 727, Vico MT 1027, Vico MT 1527 Multi-touch Panel with CODESYS HMI Web Terminal E 863 GB 01/10/2021...
  • Page 2: Table Of Contents

    Kendrion Kuhnke Automation GmbH Table of Contents Table of Contents 1 Preface ................................5 Legal Notice ............................5 Version Details ........................... 5 About this Manual ..........................5 Limitation of Liability ........................... 5 Terms of Delivery ..........................5 Copyright ............................6 Software licences ..........................
  • Page 3 Kendrion Kuhnke Automation GmbH Table of Contents Front ..............................27 Screen .............................. 27 Backlight ............................27 Touch ............................... 27 4 Installation and Operation..........................28 Mechanical Installation ........................28 Mounting Position ..........................28 Front Panel Opening ........................29 Electrical Installation ......................... 31 Operative Earth ..........................
  • Page 4 Software Copyrights ......................... 43 Drawings ............................44 Dimensions of Vico MT 727 ......................44 Installation Opening of Vico MT 727 ....................45 Font View of Vico MT 727 ........................ 45 Dimensions of Vico MT 1027 ......................46 Installation Opening of Vico MT 1027 ....................47 Front View of Vico MT 1027 ......................
  • Page 5: Preface

    - on whatever grounds - are excluded, except in instances of deliberate intent or gross negligence on our part. Terms of Delivery The general conditions of sales and service of Kendrion Kuhnke Automation GmbH shall apply. Vico MT (E 863 GB) 01/10/2021...
  • Page 6: Copyright

    CODESYS GmbH's end user licence agreement (EULA) as published on the CODESYS website. Warranty Warranty is subject to the provisions of the conditions of sale of Kendrion Kuhnke Automation GmbH or any contractual agreements between the parties. Vico MT (E 863 GB)
  • Page 7: Reliability, Safety

    Intended Use Kendrion's products are designed, developed and manufactured for standard industrial use. They must not be used for any other purposes than the ones specified in the catalogue or the associated technical documentation. Proper and safe operation depends on the products being transported, stored, lined up, mounted, installed, put into service, operated, and serviced correctly.
  • Page 8: Hazard And Other Warnings

    Kendrion Kuhnke Automation GmbH Reliability, Safety Hazard and Other Warnings Despite the actions described hereunder, the occurrence of faults or errors in electronic control units - even if most highly improbable - must be taken into consideration. Please pay particular attention to the additional notices which we have marked by symbols throughout this instruction manual.
  • Page 9 This applies to section 8 (Admissible deviations when working on parts) in particular.  Only use parts approved of by Kendrion KUHNKE. Only genuine Kendrion KUHNKE modules may be used in modular controllers. ...
  • Page 10: Security

    Reliability, Safety IT Security Kendrion Kuhnke products are designed for use in closed (private) industrial network environments. In case such industrial networks are open to public access (e.g. via fully accessible network interfaces) or otherwise externally accessible (e.g. via data links and public (Internet) traffic), the integrator and operator must take appropriate organisational and technical precautions to protect the in-house network and ensure IT security.
  • Page 11 Kendrion Kuhnke Automation GmbH Reliability, Safety Cable Routing and Wiring Keep power circuits separate from control circuits:  DC voltages 60 V ... 400 V  AC voltages 25 V ... 400 V Joint laying of control circuits is allowed for: ...
  • Page 12: Product Description

    Kendrion Kuhnke Automation GmbH Product Description 2 Product Description 2.1 General Description Vico MT panel series devices are designed for use as a multi-touch control panel in industry and building automation. By default, the panels feature a high-quality, high-resolution display with a large aspect angle and a powerful Quad Core™...
  • Page 13: Hardware Versions

    Product Description Hardware Versions The unit sells with screens of various sizes but the same control unit at the back. Front view of Vico MT 727 Front view of Vico MT 1027 Front view of Vico MT 1527 Vico MT (E 863 GB)
  • Page 14: Application

    Kendrion Kuhnke Automation GmbH Product Description 2.2 Application Intended Use The panel is designed for on-site use in industrial environments immediately at the machine. It installs in switching cabinets, switching or control panels. This series provides devices and equipment manufacturing with a visualisation unit for different applications: Place of installation If installed in an enclosed space, the unit's front is protected against dust and water.
  • Page 15: Technical Data

    Kendrion Kuhnke Automation GmbH Product Description 2.3 Technical Data Vico MT General Specifications Product name Vico MT 727 Vico MT 1027 Vico MT 1527 Screen size / aspect ratio 7" / 17:10 10.1" / 16:10 15.6"/ 16:9 Resolution 1024 x 600 / (17:10)
  • Page 16: Dimensions

    Kendrion Kuhnke Automation GmbH Product Description Dimensions Refer to section 8 for exact dimensions  8.2 Dimensions Vico MT (E 863 GB) 01/10/2021...
  • Page 17: Construction And Functionality

    Kendrion Kuhnke Automation GmbH Product Description 3 Construction and Functionality 3.1 Brief Description The panel's powerful processor board with integrated touch screen allows users to run all display and operating functions in a single unit. It is designed for on-site use immediately at the machine. Mechanical, system and cabinet engineers benefit from the unit's flexibility when designing powerful applications with a small footprint.
  • Page 18: Labelling And Identification

    Kendrion Kuhnke Automation GmbH Construction and Functionality 3.3 Labelling and Identification Name Plate Name plate Model Kendrion Kuhnke Automation GmbH Lütjenburger Strasse 101 ⎓ 24 V / 550 mA max. Vico MT 727 23714 Malente, Germany Typ: CODESYS HMI OrderNo.: 677 810 01 Ident.No.
  • Page 19: Serial Number

    Kendrion Kuhnke Automation GmbH Construction and Functionality Serial Number The numerical code incorporates the production date and a serial number. Kendrion Kuhnke can use the numerical code to distinctly identify the model, software and hardware release date. It is a means of traceability.
  • Page 20: Transport And Storage

    Kendrion Kuhnke Automation GmbH Construction and Functionality 3.5 Transport and Storage Despite the unit's rugged construction, its components inside are still sensitive to impact and vibration. Transport and keep the unit in its original packaging and ensure that the ambient conditions are as specified at all times during transport and storage.
  • Page 21: Interfaces

    Kendrion Kuhnke Automation GmbH Construction and Functionality 3.6 Interfaces All external connectors are located on the back of the unit. All connectors are of the plug-in type. Kendrion Kuhnke Automation GmbH Lütjenburger Strasse 101 ⎓ 24 V / 550 mA max.
  • Page 22: Power Supply "24Vdc", (X1)

    Kendrion Kuhnke Automation GmbH Construction and Functionality Power Supply "24VDC", (X1) On-board power supply unit (PSU) The device is designed for an input voltage of 24 VDC (+20% /- 20%). It is protected against reverse polarity. Both the cord to the device and the power supply unit must have external protection against short circuit and overload triggering at max.
  • Page 23: Usb 2.0 Host "Usb1", "Usb2" (X9)

    Kendrion Kuhnke Automation GmbH Construction and Functionality USB 2.0 host "USB1", "USB2" (X9) The two USB host ports are made for attaching USB peripherals. They provide a max. current of 0.5 A each. Pin wiring: X4 / X5 Connector Function...
  • Page 24: Ethernet "Net1" (X5)

    Kendrion Kuhnke Automation GmbH Construction and Functionality Ethernet "NET1" (X5) The on-board 1000 Mbit base-T Ethernet adapter attaches the unit to a gigabit Ethernet network through its RJ-45 connector. It automatically detects and adapts the interface to 10BaseT or 100BaseT Ethernet networks.
  • Page 25: Serial Communication Rs-232 "X12

    Kendrion Kuhnke Automation GmbH Construction and Functionality Serial Communication RS-232 "X12" The serial COM1 port provides signals RxD, TxD, CTS and RTS at an RS232 signal level. It is not electrically isolated. Pin wiring Cable: shorter than 3 m, shielded...
  • Page 26: Microsd Card (X3)

    Kendrion Kuhnke Automation GmbH Construction and Functionality MicroSD Card (X3) The unit features a MicroSD card slot located on the right side. A MicroSD icon marks the slot. SD, SDHC and SDXC cards at capacities of up to 2 Tb are supported.
  • Page 27: Indicators And Controls

    Kendrion Kuhnke Automation GmbH Construction and Functionality 3.7 Indicators and Controls Ethernet "NET1" (X5), "NET2" (X6) Both LAN1 and LAN2 Designation Explanation NET1 NET2 no activity, no link flashing green activity, link no link 1000 yellow link 1000 3.8 Front The chemically strengthened and toughened glass resides in a milled aluminium frame without edges.
  • Page 28: Installation And Operation

    Kendrion Kuhnke Automation GmbH Construction and Functionality 4 Installation and Operation WARNING Consider the standards and regulations applicable in the country of use Improper installation may cause death and serious personal or property damage. Consider all standards and regulations applicable in the country of use and only have trained experts knowing all the formalities install the unit in machines or systems.
  • Page 29: Front Panel Opening

    Kendrion Kuhnke Automation GmbH Construction and Functionality Front Panel Opening • Cut an opening into the control panel area where you wish to install the unit. Refer to the appropriate drawing or table to find the correct dimensions. Front Panel Opening...
  • Page 30 Kendrion Kuhnke Automation GmbH Construction and Functionality NOTE Damage to the mounting elements Take heed of the maximum tightening torque to avoid damaging the screws of the mounting hardware.  Tighten the screws of the mounting hardware to max. 0.2 Nm.
  • Page 31: Electrical Installation

    Kendrion Kuhnke Automation GmbH Construction and Functionality 4.2 Electrical Installation The connectors are located on the back of Vico MT or as described in section  3.6 Interfaces. Proceed in the order below to wire up the unit: • turn off the unit, •...
  • Page 32 Kendrion Kuhnke Automation GmbH Construction and Functionality Power supply ratings Supply voltage: +24 VDC ± 20 % Current consumption: 0.15 A – 1 A Power consumption: 3.6 W – 24 W Internal fusing: 2 A fuse Overvoltage category II, max. 300 V, on the primary side Recommended PSU rating: Voltage/output power: 24 VDC / min.
  • Page 33: Putting Into Service

    Kendrion Kuhnke Automation GmbH Construction and Functionality 4.3 Putting into Service General Start-up Information CAUTION Risk of burns The surface of the device may become very hot. Unprotected contact causes a risk of burning yourself.  Avoid direct contact with the unit in operation. Put on suitable safety gloves before touching the unit.
  • Page 34: Security

    Kendrion Kuhnke Automation GmbH Construction and Functionality 4.4 IT Security Automation devices contain functional units that should be protected. These include the conventional control and regulation functions and algorithms but also the facility users' production and other data. Since there is no automation solution without faults, some potential weak points and causes of risks remain.
  • Page 35: Configuration

    Kendrion Kuhnke Automation GmbH Construction and Functionality 4.5 Configuration Use a web interface or the on-board utility to configure the units of this series. You can choose to start the configuration utility either directly by picking the appropriate option as the unit starts up or by running an Internet browser on an external device and configuring the unit via its Ethernet connection.
  • Page 36: Diagnosis

    Kendrion Kuhnke Automation GmbH Construction and Functionality 4.6 Diagnosis 4.7 Table of Faults Table of Faults Fault Possible Cause Recommended Action No function Power not or incorrectly supplied to the Check that X1 is wired correctly. Measure unit the voltage supplied.
  • Page 37: Maintenance / Servicing

    Kendrion Kuhnke Automation GmbH Construction and Functionality 4.8 Maintenance / Servicing General Only qualified persons are allowed to work on the unit. CAUTION Do not plug, mount, unplug or touch the connectors during operation! Destruction or malfunction  Turn off all power sources before working on the unit. This also applies to any peripherals connected such as encoders, programming devices with external power source, etc.
  • Page 38: Life Expectancy

    Kendrion Kuhnke Automation GmbH Construction and Functionality 4.9 Life Expectancy Repairs / Customer Service Information Only the manufacturer or customer service providers authorised by the manufacturer are allowed to do repairs and perform corrective maintenance. Warranty The statutory period and conditions of warranty apply. Warranty expires if unauthorised attempts are made to repair the unit / product or any other intervention is performed.
  • Page 39: System Configuration

    Kendrion Kuhnke Automation GmbH Construction and Functionality 5 System Configuration The on-board web interface provides many user-friendly configuration options as well as sophisticated software add-ons for the specific needs of industry users. The sections below are brief descriptions of the configuration options.
  • Page 40: Display

    Kendrion Kuhnke Automation GmbH Construction and Functionality Display Use the Display page to set the logos to appear at startup, the display brightness and the touch front calibration. Time Date Since Vico MT-series devices do not buffer the time, you will have to reload the time from the Internet every time you start the unit.
  • Page 41: Log

    Kendrion Kuhnke Automation GmbH Construction and Functionality This page displays up-to-date log details. Log Persistent Choose this menu item to set up "persistent logging" on a data medium. Terminal This menu item provides a simple terminal utility. It does not support commands needed for permanent communication (e.g.
  • Page 42: System Functions

    Kendrion Kuhnke Automation GmbH Construction and Functionality 5.3 System Functions Keyboard The configuration includes support of American USB keyboard layouts without further ado. Mouse Support USB mice a supported by default. As soon as a USB mouse has been detected, the mouse pointer will appear on the screen and disappear again when the USB mouse is removed.
  • Page 43: Appendix

    Kendrion Kuhnke Automation GmbH Construction and Functionality 6 Appendix 6.1 Software Copyrights The unit's software contains product components of third-party software makers. This section summarises the copyright details regarding the software resources concerned. CODESYS Control runtime system Equipment manufacturers installing the CODESYS runtime system on their devices are sent a licence file...
  • Page 44: Drawings

    Kendrion Kuhnke Automation GmbH Construction and Functionality 6.2 Drawings Dimensions of Vico MT 727 Vico MT (E 863 GB) 01/10/2021...
  • Page 45: Installation Opening Of Vico Mt 727

    Kendrion Kuhnke Automation GmbH Construction and Functionality Installation Opening of Vico MT 727 Font View of Vico MT 727 Vico MT (E 863 GB) 01/10/2021...
  • Page 46: Dimensions Of Vico Mt 1027

    Kendrion Kuhnke Automation GmbH Construction and Functionality Dimensions of Vico MT 1027 Vico MT (E 863 GB) 01/10/2021...
  • Page 47: Installation Opening Of Vico Mt 1027

    Kendrion Kuhnke Automation GmbH Construction and Functionality Installation Opening of Vico MT 1027 Front View of Vico MT 1027 Vico MT (E 863 GB) 01/10/2021...
  • Page 48: Vico Mt1527

    Kendrion Kuhnke Automation GmbH Construction and Functionality Vico MT1527 Vico MT (E 863 GB) 01/10/2021...
  • Page 49: Installation Opening Of Vico Mt1527

    Kendrion Kuhnke Automation GmbH Construction and Functionality Installation Opening of Vico MT1527 Front View of Vico MT1527 Vico MT (E 863 GB) 01/10/2021...
  • Page 50: Applicable Standards And Limits

    Kendrion Kuhnke Automation GmbH Construction and Functionality 6.3 Applicable Standards and Limits EMC Standards  EMC noise emission pursuant to IEC 61000-6-4 (industrial environments)  EMC noise immunity pursuant to IEC 61000-6-2 (industrial environments) Admissible Ambient Conditions Storage and transport Temperature ........
  • Page 51: Regulations And Declarations

    Kendrion Kuhnke Automation GmbH Construction and Functionality 6.4 Regulations and Declarations Mark of Conformity The EC-Declarations of Conformity and the associated documentation can be made available to the competent authorities pursuant to the above EU Directive. Please contact the Project Management, as necessary.
  • Page 52: Order Specifications

    Kendrion Kuhnke Automation GmbH Construction and Functionality 6.6 Order Specifications Basic Units Technical Data Vico MT 727 HMI 677 810 00 CODESYS HMI terminal with multi-touch screen 7-inch TFT display, wide format (1024x600), typ. 450 cd/m2 Capacitive multi-touch screen, glass 1.8 mm thick Glass front resides in milled aluminium frame (with end caps) Processor ARM Cortex A53, i.MX8Mmini quad-core CPU, 4x 1.6 GHz...
  • Page 53: Accessories

    Kendrion Kuhnke Automation GmbH Construction and Functionality Accessories Vico MT (E 863 GB) 01/10/2021...
  • Page 54 Kendrion Kuhnke Automation GmbH Industrial Control Systems Lütjenburger Str. 101 D-23714 Malente Tel.: +49 4523 402 0 Fax: +49 4523 402 201 sales-ics@kendrion.com www.kendrion.com...
