Service Manual
Sequence for All Other Software Versions
Press
FREEZE/UNFREEZE
FREEZE/UNFREEZE
SETUP
ALARMS
SUSPEND (on menu)
ALARM SUSPEND/RESUME (button)
ALL ALRM
LIMITS
NEXT
MAIN MENU (button)
NIBP START/STOP (button)
NIBP START/STOP (button)
1. Press ECG/RESP > MORE. Then press CHANGE to select the four HR/PR TONE
levels. Verify that the tone volume changes and goes off when turned OFF . Set the
volume to LOW.
2. Press MAIN MENU.
3. Software versions 2.5X: Press SETUP > MORE > MORE > SERVICE > YES > MORE
> MORE > SETTINGS > ALL ALRM. Verify alarm status displays "TURNING OFF ALL
AUDIBLE VITAL SIGNS ALARMS", "ARE YOU SURE?", YES or NO. Then press MAIN
MENU.
4. All software versions: Press SETUP > MORE > MORE (> TIME/DAY for monitor
software less than version 2.0) and check that the displayed time and date are correct.
If incorrect, press NEXT and UP or DOWN to select and change the time and date,
and then set by pressing the ENTER button.
5. Turn off the monitor.
ECG/RESP Channel and Alarm Indicators
The following procedures verify the ECG channel and the alarm indicator drivers. The
setup procedure below is used for both the visual and the electrical checks that follow.
Setup
1. Turn on the monitor and verify that it powers up correctly.
2. Put the monitor into FACTORY ADULT MODE.
Software version 2.XX: SETUP > MORE > CHANGE > SETUP > USE NOW > YES
Software version 1.XX: SETUP > MORE > CHANGE > ADULT > YES > MORE >
PROGRAM > DEFAULT > YES
3. Press MAIN MENU.
Result
Freezes the waveforms
Unfreezes the waveforms
Changes the menu
Changes the display to ALARM STATUS
SUSPEND changes to RESUME
Changes RESUME to SUSPEND
Changes display: Turn All Off, Are You Sure, Y or N
Changes display to HR Limits
Moves cursor block: Next block within selected parameter limits, NEXT
PAGE to next parameter
Returns to the main menu
Starts the NIBP pump
Stops the NIBP pump
Functional Verification 17
