- Page 1 ® Solo ioSafe USB 2.0 • Fireproof • Waterproof • FloSafe Cooling Technology • Disaster Recovery Service • External Hard Drive...
- Page 2 COPYRIGHTS Copyright ioSafe, Inc. 2009. All rights reserved. No part of this publication may be reproduced or transmitted in any form by any means, electronic, mechanical photocopying, recording or otherwise, without prior written consent. TRADEMARKS All Trademarks mentioned or appearing in this document are the property of their respective owners.
- Page 3 interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. However, if this equipment does cause interference to radio or television equipment reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...
-
Page 4: Table Of Contents
Precautions ... 7 Package Contents ... 8 Specifications ... 9 System Requirements ... 10 Securing the Solo... 13 Connecting the Solo to Your Computer ... 14 ioSafe Disaster Recovery Service ... 18 Following a Disaster ... 21 ioSafe Warranty... 24... -
Page 5: Welcome
- the first high capacity external hard drive available with protection from fires and floods. For years, ioSafe has continued to set the standard for disaster proof hardware. The ioSafe Solo brings our technology forward with an unprecedented combination of security, reliability, capacity and price. - Page 6 data contained in the device to meet the following specifications: • Fire Endurance Testing: temperatures up to 1,550° F for a duration of 30 minutes per ASTM E119 fire testing protocol. • Full Water Submersion: depth of 10 feet in fresh water or salt water for 3 days (72 hours)
-
Page 7: Precautions
• If you are using the Solo for general storage (as opposed to data backup) we strongly recommend that you backup your data. The company is not responsible for data loss or corruption. -
Page 8: Package Contents
Package Contents Included in the package: A. ioSafe Solo external hard drive B. AC power adapter C. USB Cable D. Users guide (this booklet) -
Page 9: Specifications
Dimensions (inches)……………...5.0W X 7.1H X 11.0L Weight (Lb)………………………………………………….……….15 Interface Transfer Rate (USB 2.0)…….…….480 Mbps External Power Supply AC Input……………100-240V, 50-60 Hz, 1.0 A DC Output…...12V @ 2 A Ambient Temperature Operating……………………………..…..…40 - 95°F Non-operating………………………….0 – 1,550°F Up to 30 minutes per ASTM E119 Humidity Operating (non-condensing)...……20 –... -
Page 10: System Requirements
PC Requirements • A PC with a 233 MHz or faster processor • One of the following operating systems Windows Vista (Ultimate, Home Basic/Premium, Business) Windows XP with Service Pack 1 or later (Home, Professional, Professional X64, Media Center Edition) •... -
Page 11: Mac Requirements
Mac Requirements • G3 (or later), or Intel processor • Mac OS 10.3 or later • A free USB 2.0 port Mac OS 10.2 will not recognize NTFS file systems, the default for the Solo. Mac OS 10.3 will recognize the Solo, but requires formatting once connected. - Page 12 versa. However, interface transfer rates are limited by the interface with the lower speed. If you plug the Solo into a USB 1.1 port on your computer, data transfer rates will be limited to USB 1.1 speeds (up to 12 Mbps).
-
Page 13: Securing The Solo
Securing the Solo (Suggestions) For added security, the Solo can be bolted to a floor or secured with a cable and padlock. See the pictures below for suggested methods on physically securing the Solo. -
Page 14: Connecting The Solo To Your Computer
Step 1: Plug in the AC plug adapter and power cord 1. Plug the small end of the AC adapter into the Solo’s power port. 2. Plug the adapter into an AC outlet. Step 2: Connecting the USB Cable The USB cable has a flat connection on one end, and a square connection on the other end. - Page 15 means that the computers operating system has recognized at least one readable partition on the drive, and established a communication link with it. For Windows, once the Solo is powered on the operating system should mount the drive in a few moments. A new drive icon/letter will appear in My Computer/Windows Explorer.
- Page 16 Extended. 4. In the Name field, type in a unique name for the Solo that will allow you to easily distinguish it from other storage devices attached to your computer. 5. Click Erase. You should see and alert message: “Erasing a disk will destroy all information on all of the volumes of the disk…”...
- Page 17 listed in the Disk Utility. You will see the Drive Icon on the Desktop and in the Finder.
-
Page 18: Iosafe Disaster Recovery Service
Terms and Conditions As applicable during the Disaster Recovery Service period and upon validated registration of an ioSafe (the Company) product on the Company's website (www.iosafe.com), the Company or its contracted partner will assist the original purchaser for one "disaster recovery event". The Company will attempt to... - Page 19 recovery by the Company is not successful, the Company will pay up to $1,000 USD to a third- party disk recovery service of the Company's choice to extract the data. Any data extracted will be loaded on a replacement product and shipped back to the original user.
- Page 20 program for products registered to the original purchaser only.
-
Page 21: Following A Disaster
In other cases, ioSafe may request that the Solo be returned to the ioSafe factory for data recovery. In any case, calling ioSafe is the first step. The general steps for natural disaster recovery are: 1. - Page 22 4. Wait for the ioSafe device to cool down if post- fire 5. Drain any free water from the ioSafe device if post-flood 6. Place the ioSafe device in a heavy duty plastic garbage bag 7. Place the bagged ioSafe device in a small...
- Page 23 15. Once the primary server / computer is repaired or replaced, the original user should restore the primary drive data with the ioSafe backup data 16. Continue to use the ioSafe device for subsequent backups...
-
Page 24: Iosafe Warranty
Warranty If a mechanical or operable part of an ioSafe malfunctions or breaks down during normal use, ioSafe will at our option, repair or replace said part free for a period of three (3) years from the date of purchase. - Page 25 consequential damages, so the above limitation may not apply to you. This warranty gives you specific legal rights, and you may have other rights as well, which will vary from state to state.
