This user's guide describes the operation and configuration of the evaluation module (EVM) for the
DRV600 stereo line driver. The document also provides measurement data and design information,
including a schematic, bill of materials, and layout figures.
......................................................................................................................
1
2
.....................................................................................................................
3
4
5
6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
1
2
3
4
5
6
7
Related Documentation from Texas Instruments
8
9
All trademarks are the property of their respective owners.
SLOU205 - July 2007
Submit Documentation Feedback
This datasheet has been downloaded from
...........................................................................................................
.................................................................................................
....................................................................................................
.................................................................................................................
.......................................................................................
...........................................................................................
............................................................................................
..........................................................................................
........................................................................................
.......................................................................................
...................................................................................................
.........................................................................................................
......................................................................................................
...........................................................................................................
.........................................................................................................
.........................................................................................................
..................................................................................................
.............................................................................
.............................................................................................................
.........................................................................................................
............................................................................................................
............................................................................................
................................................................................................
................................................................................................................
....................................................................................................
......................................................................................................
....................................................................................................
.........................................................................................................
DRV600EVM User's Guide
Contents
......................................................................
List of Figures
.............................................................................
............................................................
List of Tables
......................................................................
http://www.digchip.com
User's Guide
SLOU205 - July 2007
DRV600EVM User's Guide
at this
page
2
4
5
6
11
12
2
3
4
5
7
7
7
8
8
9
9
10
10
11
11
12
14
14
14
2
5
6
6
6
6
11
13
13
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments DRV600EVM
Summary of Contents for Texas Instruments DRV600EVM
-
Page 1: Table Of Contents
...................... Frequency Response ......................Phase Response ......................Pop/Click (Enable) ......................Pop/Click (Disable) ....................DRV600EVM Schematic ................DRV600EVM PCB Component Side (Top) ......................PCB Top Layer ......................PCB Bottom Layer List of Tables ......................DRV600 Features .................... Recommended Supply Voltage .................... -
Page 2: Overview
Overview Overview The DRV600EVM evaluation module demonstrates the capabilities and performance of the DRV600RTJ from Texas Instruments. The DRV600 is a stereo line driver designed to allow the removal of the dc-blocking capacitors typically found in an audio application, reducing overall component count and cost. The DRV600 is ideal for single-supply electronics where size and cost are critical design parameters. -
Page 3: Drv600 Functional Block Diagram
Audio Out - R SVSS Short-Circuit Protection SGND SVDD Audio Out - L Audio In - L SVSS AV = 1.5V/V Charge Bias Pump Circuitry PVSS Figure 2. DRV600 Functional Block Diagram SLOU205 – July 2007 DRV600EVM User's Guide Submit Documentation Feedback... -
Page 4: Quick Setup Guide
Figure 3. DRV600EVM Physical Structure Quick Setup Guide This section describes the DRV600EVM with regard to power supply and the system interface. It also provides information about handling and unpacking the module, absolute operating conditions, and a description of the factory default switch and jumper configuration. -
Page 5: Shutdown
For minimum click and pop interference during power-up and power-down, the shutdown pin should be kept low. The preferred power-up/-down sequence is shown in Figure DVDD SHUTDOWN > 50 s > 50 s Figure 4. Recommended Power-Up/-Down Sequence SLOU205 – July 2007 DRV600EVM User's Guide Submit Documentation Feedback... -
Page 6: Drv600Evm Performance
All electrical and audio specifications are typical values. Table 6. Physical Specifications PHYSICAL SPECIFICATIONS NOTES/CONDITIONS PCB Dimensions 50 x 60 x 25 Width x Length x Height (mm) Total Weight 35g Components + PCB + Mechanics DRV600EVM User's Guide SLOU205 – July 2007 Submit Documentation Feedback... -
Page 7: Thd+N Vs Voltage (600Ω Load)
4.5V DVDD 0.01 0.001 100m Figure 6. THD+N vs Voltage (100kΩ load) THD+N vs Frequency (600Ω load) 0.01 0.2V 0.001 10k 20k Frequency (Hz) Figure 7. THD+N vs Frequency (600Ω load) SLOU205 – July 2007 DRV600EVM User's Guide Submit Documentation Feedback... -
Page 8: Thd+N Vs Frequency (600Ω Load) Using X7R Input Caps
DRV600EVM Performance The DRV600EVM uses a 1μF film capacitor for ac-coupling of the input signal. If a lower cost ceramic capacitor such as an X7R is used, higher THD at low frequencies should be expected. Y5V capacitors will show even higher THD performance and should not be used. -
Page 9: Idle Noise Fft Spectrum
Channel 1 output signal is 2V ; channel 2 input is grounded. Reference voltage is 2V ; the load is 600Ω. -100 -110 -120 10k 20k Frequency (Hz) Figure 11. Channel Separation SLOU205 – July 2007 DRV600EVM User's Guide Submit Documentation Feedback... -
Page 10: Frequency Response
The low frequency cutoff of 10Hz (–3dB) is determined by the input ac-coupling capacitor together with the input impedance of the DRV600. A 1μF capacitor is used on the DRV600EVM. The input impedance of the DRV600 is 15kΩ. This impedance gives a –3dB cutoff of 10Hz. This result corresponds with the frequency response measurements above. -
Page 11: Related Documentation From Texas Instruments
Related Documentation from Texas Instruments Table 7 contains a list of documents that have a detailed description of the integrated circuits used in the design of the DRV600EVM. The data sheet can be obtained through the TI website. Table 7. Related Documentation from Texas Instruments... -
Page 12: Design Documentation
Design Documentation Design Documentation This section includes a schematic for the DRV600EVM as well as the bill of materials (BOM) and the PCB design specifications. Schematic Line Driver +3.3V 100k 100k Header Header 1.8V to 4.5V Power supply Switch... -
Page 13: Drv600Evm Parts List
J11 J12 J21 J22 Horizontal Female w. Switch Coax Phono socket Chunfeng RJ843-4W Switch 6mm SMD Tactile Switch Switch Omron B3S-1000 PCB11 A832-PCB-001_2.00 / DRV600EVM Printed Circuit Printline A832-PCB-001(2.00) Board (ver. 2.00) PCB Specifications Table 9. PCB Specifications BOARD IDENTIFICATION A832-PCB-001(2.00) BOARD TYPE... -
Page 14: Drv600Evm Pcb Component Side (Top)
Note: Board layouts are not to scale. These figures are intended to show how the board is laid out; they are not intended to be used for manufacturing DRV600EVM PCBs. Figure 17. DRV600EVM PCB Component Side (Top) Figure 18. PCB Top Layer Figure 19. - Page 15 EVALUATION BOARD/KIT IMPORTANT NOTICE Texas Instruments (TI) provides the enclosed product(s) under the following conditions: This evaluation board/kit is intended for use for ENGINEERING DEVELOPMENT, DEMONSTRATION, OR EVALUATION PURPOSES ONLY and is not considered by TI to be a finished end-product fit for general consumer use. Persons handling the product(s) must have electronics training and observe good engineering practice standards.
- Page 16 TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated products in automotive applications, TI will not be responsible for any failure to meet such requirements. Following are URLs where you can obtain information on other Texas Instruments products and application solutions: Products...
