IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 Pc.
B.
C.
Side Frame
Side Frame
1 Pc.
1 Pc.
Hardware List
Small
Hex Wrench
1 pc.
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver
D.
E.
Back Frame
Back Frame
1 Pc.
1 Pc.
Head Cap Bolt
Head Cap Bolt (long)
28 pcs. (+1 extra)
2 pcs. (+1 extra)
Head Cap Bolt
Wood Screw (long)
(for connecter)
8 Pcs. (+1 extra)
4 pcs. (+1 extra)
F.
Rail
1 Pc.
G.
Shelf
2 Pcs.
Spring Washer
Flat Washer
30 pcs. (+1 extra)
30 pcs. (+1 extra)
Wood Screw (short)
4 Pcs. (+1 extra)
Steel Plate Connecter
2 Pcs. (+1 extra)
