Stylus Condition; Screen Cleaning; Normal Wear And Tear Considerations - Itronix GoBook II Product Support Bulletin

For environments with high contaminant potential, For environments with high contaminant potential, use of an Itronix provided T For environments with high contaminant potential,
For environments with high contaminant potential, For environments with high contaminant potential,
1 A Screen overlay provides protection from damages caused by use of foreign objects and/or surface contaminants and maximizes
useful life of the Touch Screen. Worn, scratched, or otherwise damaged Screen overlays can simply be removed and replaced.
2 With the overlay applied, contaminants on the screen's surface should be removed by following the same cleaning methods noted
for Touch Screen cleaning in this document.
3 Screen overlay installation has negligible impact to overall display brightness/viewability and can provide enhanced screen
clarity while maximizing useful life of the Touch Screen surface.
NOTE Screen Overlay kits may be ordered by contacting your Itronix Representative.
Normal W Normal W ear and T ear and T ear Considerations ear Considerations
Normal W Normal Wear and T Normal W ear and T ear and Tear Considerations ear Considerations ear Considerations

Stylus condition:

Stylus condition: Stylus condition: Stylus condition: Stylus condition:
1 The Stylus should never be used for anything other than GoBook Touch Screen input. Foreign materials and/or imperfections on
the stylus tip from improper use can cause excessive wear or damage to the screen surface. This damage is not considered normal wear
and tear and may have warranty implications.
2 The stylus tip will wear and collect foreign debris with normal use. The foreign debris and/or wear can eventually lead to screen
surface damage. Subsequently; stylus replacement should be performed on a routine basis. Replacement intervals should follow a
10,000 cycle routine. Average daily stylus use is approximately equivalent to 10,000 cycles every 4 months. High use environments
should follow a shorter replacement cycle of 3 months or less. (Cycle Definition below)
A cycle is defined as a full character input and is simulated in test using a sinusoidal waveform as character input
over a 30mm x 30mm area. The screen surface, both with and without screen overlay installation, is life cycle tested
to over 100,000 cycles with a down pressure weight of 250 grams. This testing is meant to simulate a useful life of
3-5 years. Testing results following 100,000 cycles found no degradation in optical performance (readability) or
functionality.
NOTE Replacement Stylus kits may be ordered by contacting your Itronix Representative.

Screen Cleaning:

Screen Cleaning:
Screen Cleaning: Screen Cleaning: Screen Cleaning:
1 Touch Screen cleaning performed using ammonia based products such as commercial/retail glass cleaners can cause irreversible
damage to the screen surface and anti-glare hard coat. This damage is not considered normal wear and tear and may have warranty
implications.
2 Paper products such as paper towels and wipes are abrasive in nature and should not be used for any screen cleaning tasks. The
abrasive properties of these paper based products act much like a fine sandpaper when used on the screen surface and can cause
irreversible damage to the screen surface and anti-glare hard coat. This damage is not considered normal wear and tear and may have
warranty implications.
3 Foreign materials and/or debris on the Touch Screen surface can lead to excessive wear or damage when combined with stylus or
clean finger tip use. With this noted; the screen surface should be kept clean and free of foreign materials, stylus tips should be
routinely inspected for signs of wear and/or imperfections, and only clean well manicured finger tips should be used.
4 Cleaning with a Screen Overlay installed should follow the same Itronix approved touch screen cleaning methods detailed in this
document. This includes use of the Itronix provided cleaning cloth; dry, with water, or an Isopropyl Alcohol/Water (50/50) solution,to
ensure a full useful life of the overlay
use of an Itronix provided Touch Screen overlay is recommended: use of an Itronix provided T use of an Itronix provided T
use of an Itronix provided T
ouch Screen overlay is recommended: ouch Screen overlay is recommended: ouch Screen overlay is recommended:
ouch Screen overlay is recommended:
