Kohler 22327T-7 Installation Instructions Manual

INSTALLATION INSTRUCTIONS
22327T-7
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Risk of electric shock. Connect only to circuits protected by a Ground-Fault Circuit-Interrupte (GFCI) or
Residual Current Device (RCD). Grounding is required.The unit should be installed and grounded by a qualified
service representative.
2. Risk of electric shock. A licensed electricia should route all electrical wiring.
Risk of electric shock. Disconnect power before servicing.
3.
4. Risk of injury or property damage. Please read all instructions thoroughly and determine all required compo-
nents along with their installation locations before beginning installation.
5. Do not apply excessive heat near the valve or apply flux or acids directly onto the valve. This valve contains
plastic and rubber components which will melt if heat is directly applied.
6. Do not apply petroleum-based lubricants to the valve components. Doing so will damage valve components.
7. Do not use oil-based, non-setting compounds, such as plumbers putty, on the threaded connections.
8. Observe all plumbing, electrical and building codes.
9. Make sure both hot and cold supply pipes are flushed thoroughly prior to connection to the Digital Mixer Valve.
10. If possible, install valve prior to installing the interface(s). When installing electrical outlet, please install an
on/off switch in a suitable position for easy operation during network connection and troubleshooting.
11. Do not plug or unplug cables on valve when the valve is power-on, which may damage the product.
STANDARD APPLICABLE
Special model meets or exceeds the following at date of manufacture: TIS
SPECIFICATION
Pressures
Maximum Static Pressure
Maximum Maintained Pressure
Minimum Maintained Pressure
Supply Pressure Differential
Minimum Flow Rate
Temperatures
Maximum Temperature (factory preset)
Maximum Temperature (setting range)
Minimum Temperature
Hot Water Range
Cold Water Range
Temperatures Stability
Ambient Temperature
Maximum Relative Humidity
Electrical
Supply Voltage
1354659-2A-C
DTV MODE
Dual Shower Set
1MPa (10 bar)
500 kPa (5 bar)
50 kPa (0.5 bar)
Max 34.5 kPa (0.34 bar)
6 L/Min
45°C
41°C - 48°C
Thermostatic control down to 30°C／15°C(IOT version)
55°C - 65°C
1°C - 20°C
± 1°C at recommended supply conditions
1°C - 40°C
95% non-condensing
100-240V, 2A, 50 Hz/60 Hz
