产品参数
6
freedom
Payload 250g
Arm spread 350mm
Working radius 280g
Repetitive
±0.5mm
positioning accuracy
dead weight 1030g
Power input 8-12V , 5A
work environment -5°C~45°C
signal communication USB Type-C
副控板参数
model ATOM
ESP32,240MHz Dual-core
chip
520KB SRAM
FIash 4MB
Installation position Installation position
LED display WS2512C 2020 X25
Non open source,
Software
can burn firmware
主控板参数
GPU 128-core NVIDIA Maxwell
Quad-core ARM
CPU
®A57 @ 1.43 GHz
2 GB 64-bit LPDDR4
Memory
25.6 GB/s
wireless 802.11ac
internet access *1
Video HDMI*1
IO mouth 40个
-18 -
myCobot
MIPI CSI-2
camera connector
40-pin expansion header
Micro-USB port
for Device Mode
Atom 介绍图
Atom 功能引脚图
