Summary of Contents for Clarion OHM642
-
Page 1: Color Monitor
6.4” LCD Color Monitor OWNER’S MANUAL... -
Page 2: Table Of Contents
OHM642 INTRODUCTION The Clarion OHM642 is a full-featured 6.4" LCD Color Monitor that can be used as a stand alone monitor, or can be integrated into a mobile multimedia system. The OHM642 has the following features: 6.4" color LCD panel... -
Page 3: Description
DESCRIPTION The OHM642 is a TFT active matrix color LCD monitor that delivers a striking pic- ture and superior image resolution. The OHM642 can be used to enjoy video images with the Clarion video sources, even if no TV tuner is connected. -
Page 4: Wiring Precautions
The OHM642 is an overhead, fold-down 6.4" monitor with an Infrared (IR) eye. It will accept a video signal from any video source with composite video out. The IR eye will work directly with any Clarion video source product with an IR Eye Input. -
Page 5: Mounting Options
PICTURE ADJUSTMENT To adjust the picture brightness, use the Brightness UP and DOWN buttons located on the front panel of the OHM642. Press the UP button to increase the picture brightness. Press the DOWN button to decrease the picture brightness. -
Page 6: Product Specs
OHM642 SPECIFICATIONS GENERAL SPECIFICATIONS: Power Requirement: Power Consumption: Weight: Dimensions: Operation Temperature: Supplied Accessories: MONITOR SPECIFICATIONS: Display Type: Screen Size: Pixels: Screen Resolution: Video System: DC 12V (9-16V) 0.8A Max. (0.8A or Less) 2.2 lb. (1.0kg) 9.1" x 12.7" x 1.9"... -
Page 7: Notes
OWNER’S MANUAL NOTES:... - Page 8 661 West Redondo Beach Blvd. Gardena, CA 90247 1-800-GO-CLARION www.clarion-usa.com...
