Page 1: Color Monitor
5” LCD Color Monitor OWNER’S MANUAL... -
Page 2: Table Of Contents
VMA5091 INTRODUCTION The Clarion VMA5091 is a full-featured 5" LCD Color Monitor that can be used as a stand alone monitor, or can be integrated into a mobile multimedia system. The VMA5091 has the following features: 5" color LCD panel... -
Page 3: Description
DESCRIPTION The VMA5091 is a TFT active matrix color LCD monitor which delivers a striking picture and superior image resolution. The VMA5091 can be used to enjoy video images with the Clarion video sources, even if no TV tuner is connected. -
Page 4: Wiring Precautions
INSTALLATION The VMA5091 is a 5" monitor with an Infrared (IR) eye. It will accept a video signal from any video source with composite video out. The IR eye will work directly with any Clarion video source product with an IR Eye Input. -
Page 5: Mounting Options
The included trim rings allow the monitor to be installed at various angles to guarantee a perfect install. In addition to this mounting bezel, the VMA5091 has a 1/4-20 threaded hole as well as a slot on the back to accommodate a variety of mounting options. - Page 6 VMA5091 SPECIFICATIONS GENERAL SPECIFICATIONS: Power Requirement: Power Consumption: Weight: Dimensions: Operation Temperature: Supplied Accessories: MONITOR SPECIFICATIONS: Display Type: Screen Size: Pixels: Screen Resolution: Video System: DC 12V (9-16V) 0.8A Max. (0.8A or Less) 1.3lb (0.6kg) 5.5" x 4.4" x 1.2"...
-
Page 7: Notes
OWNER’S MANUAL NOTES:... - Page 8 661 West Redondo Beach Blvd. Gardena, CA 90247 1-800-GO-CLARION www.clarion-usa.com...
