socket
Figure 19: The enclosure rod being bent and inserted
into the socket
Figure 20: The completed trampoline with enclosure
C-clip
socket
Figure 21: C-clip attaching to socket on frame
Springfree™ Trampoline Model SF80 Trampoline and Enclosure Assembly, Installation, Care, Maintenance and Use Instructions Version 1.0
Step 19: Bending the enclosure rod
into it's socket
Bend the rod and insert the bottom end into
the socket on the frame (Figure 19). Ensure that
the rod is pushed right down into its socket
and locked in place by the C-Clip. Next, insert
the enclosure rod on the opposite side of the
trampoline.
Step 20: Completing the enclosure
Insert remaining enclosure support rods by the
same process: put the top ball through the loop
into the pocket, hoist the rod, then insert the
bottom end of the rod into the socket by the
leg.
Ensure the joiner-lock is engaged, holding
the short and long pieces of the enclosure rod.
Also, ensure that the rod is pushed right down
into its socket and locked in place by the C-Clip.
Again, ensure rods are pushed right to the
ends of the pockets so the internal catches will
prevent them from coming out.
Step 21: Checking C-Clips are secure
in sockets
C-clips should be pre-installed onto the sockets.
Check and ensure the 12 C-clips are on the
sockets. Ensure these clips capture the rods and
prevent them from being pulled out.
Congratulations! You have successfully
completed the assembly of your Springfree™
Trampoline!
Be sure to review all warnings and precau-
tions with your family before using. Happy
jumping—the Springfree™ Trampoline way!
19
