Springfree SF80 Assembly, Installation, Care, Maintenance, And Use Instructions page 14

Tip: Follow Steps 8
and 9 very carefully to
place the enclosure
net properly. Not
following these steps
carefully may result in
the enclosure being
installed inside out.
WARNING: Ensure rods are seated
right down to the bottom of each
socket. Rods that are improperly
seated may eject unexpectedly,
which may cause injury.
14
Step 8: Positioning the enclosure
Lay the enclosure net around the frame with
the enclosure door (the zippers) between two
legs on a straight frame section (Figure 8).
Ensure the inside of the enclosure is up. The
enclosure pockets are on the outside at the top
of the net, and should be down.
Step 9: Inserting the irst rod
Find the strip at the lower part of the net with
the holes in it. Select the hole that has a label
"1st Rod Position" sewn next to it (Figure 9-A).
Find the rod socket on the straight frame sec-
tion that has the sticker "1st Rod Position" next
to it (Figure 9-B).
Put the rod through the net hole and back
into the socket hole you have located
(Figure 9-C).
Slide the net at the hole down to the bottom of
the rod. The irst rod label should be facing out
(Figure 9-C).
Springfree™ Trampoline Model SF80 Trampoline and Enclosure Assembly, Installation, Care, Maintenance and Use Instructions Version 1.0
zipper door
Figure 8: The enclosure properly laid around the
trampoline frame
Figure 9-A: The hole strip on the enclosure
Figure 9-B: The irst rod socket
Figure 9-C: The rod going into irst socket
