Springfree SF80 Assembly, Installation, Care, Maintenance, And Use Instructions page 17

Figure 14-A: The remaining rods attached to the mat
Figure 14-B: The release clip on the mat itting
Figure 15: The enclosure being slid up the rods and up
onto the mat
Figure 16: The horizontal rods being inserted into
their sleeves in the enclosure
Springfree™ Trampoline Model SF80 Trampoline and Enclosure Assembly, Installation, Care, Maintenance and Use Instructions Version 1.0
Step 14: Attaching the remaining
rods to the mat
Now, install one more rod to the left of each
group, while circling the trampoline.
Continue to circle around the trampoline
installing one rod per group until all rods are
connected (Figure 14-A).
Tip: If you miscount, and need to release a
connected rod, release the clip before trying to
disconnect the ball from the mat socket. The
Push lever
clip is released by pushing the lever towards
towards mat
centre to
the mat centre. Apply pressure on the rod until
release ball
it is unloaded (Figure 14-B).
Step 15: Sliding the enclosure
net up the rods
Lift the enclosure net from the ground, up on
to the trampoline mat. (It may be a tight it over
the mat edge). Please ensure the net does not
snag on the frame bolts as this may tear the net.
Circling the trampoline from right to left,
slide the net bottom strip up the rods to the
top, just under the mat edge. The long zip
will now end along the straight edge of the
trampoline.
To avoid unnecessary wear on the net,
please ensure that the bottom net weave band
covers the edge of the mat.
Step 16: Inserting the horizontal
net supports
Locate the top edge of the enclosure along the
straight edges of the trampoline.
Slide the horizontal rod into the pocket along
the top enclosure edge and secure with the
Velcro tab (Figure 16).
Repeat on all straight sides of the trampoline
net.
WARNING: Treat any loaded rod
with caution until you are sure it is
properly installed or uninstalled.
Keep your face well away from any
loaded rod.
17
