Step 5: Fastening the legs to the
frame
Fasten the legs to the frame with the small bolts
and nuts provided (Figure 5). Do not over-
tighten.
If the holes do not line up, check that the
leg has been inserted properly (refer to Figure
4-C) or lift the leg slightly. The nut should be
towards the mat centre; the bolt head should
be towards the outside.
Now, repeat Step 1 through Step 5 for the
remaining two curved sections and one of the
straight sections.
Step 6: Inserting the straight frame
sections
Turn the two U shaped sections over (Figure
6-A).
Lift an end of the attached U shaped sections
and insert one side of a leg into the frame leg
socket, repeat this step on all U shaped section
ends. Leave the unconnected side of the leg
facing outwards from the trampoline centre
(Figure 6-B).
Adjust the spacing between the U shaped
sections so that the straight sections it be-
tween them (Figure 6-B).
12
Springfree™ Trampoline Model SF80 Trampoline and Enclosure Assembly, Installation, Care, Maintenance and Use Instructions Version 1.0
bolt
Figure 5: Fastening the legs to the frame
Figure 6-A: Turning the two U shaped sections over
Figure 6-B: Adjusting spacing for straight section
wrench
nut
