Step-by-Step Instructions
1
Open the side door.
3
Remove the media and transfer ribbon.
Printhead for EasyCoder F4 & F4 Compact Industrial, Installation Instructions
EasyCoder F4-Series—Printhead Replacement
2
Turn the printhead lift lever clockwise to raise the
4
Pull the printhead bracket away from the magnet in
printhead.
the pressure arm.
3
