EasyCoder 401/501 – Installation Instruction
PAPER CUTTER KIT, cont'd.
Step-by-Step Instructions
#T10 Torx Screws
Important!
Turn off the main switch and remove the power cord.
Open the printer's front hatch.
Hold the printer firmly and press the front hatch sideways to the
left so the hinges disengage.
Remove the hatch completely.
Front Hatch
Press sideways
If the printer is fitted with an optional label-taken sensor (LTS),
it must be removed, since it intrudes on the space required by the
cutter and which has no use anyway in connection with cut-off
operation.
If the printer is not fitted with an LTS, bypass the rest of this page
and page 3 and proceed at the top of page 4.
Remove the cover over the left part of the printer. It is held by
three or four #T10 Torx screws along the lower edge and another
three or four similar screws at the top.
#T10 Torx Screws
Continued!
2
