The LGG100 uses FLoader, a Windows®-based utility, to load firmware onto
the receiver and power boards. You can download FLoader to your computer
from the JNS website. For more information, refer to the FLoader User's
Manual, also available on the JNS website (http://www.javad.com).
1.
2.
3.
4.
5.
6.
7.
www.javad.com
Download and install FLoader, if applicable.
Download the new firmware package to your computer.
Physically connect your receiver and computer using the RS232 cable.
Activate FLoader (Figure 3-7).
On the Connection tab, select the COM port on your computer that connects
with your receiver and select its speed (usually 115200).
Select the Device tab and set the Device Type as Receiver (Figure 3-8).
Click Get from Device for device information (Figure 3-8).
Figure 3-7. Floader Main Screen
Figure 3-8. Set Device Type
O P E R A T I O N
Loading New Firmware
