Diagnostics
The system's microprocessor monitors and reports all active and violated zones when arming and
disarming. LED flashes indicate the active or violated zone; siren chirps indicate system status.
Arm/Disarm Diagnostics
The number of siren chirps will indicate the status of the system when arming and disarming. For
information on which zone is active or has been violated refer to the Table of Zones.
System Status Chirps
Action
Number of Chirps
Arm
1
Arm
1 (3 second delay), 1
Disarm
2
Disarm
4
Disarm
5
Table of Zones
Zone
DESCRIPTION
(LED Flashes)
1
Instant trigger - hood pinswitch
2
Instant trigger - a heavier impact
detected by the shock sensor
3
Door switch trigger
4
Instant trigger - for optional sensors
5
Ignition trigger
NOTE: The Warn Away® response does not report on the LED.
©
2003
Directed Electronics, Inc.
Description
System armed
System armed with Bypass Notification
System disarmed
System disarmed with Tamper Alert
System disarmed NPC
™
active
LCD Icon
Hood Open and Trigger Alert Icon
Full Trigger Shock Sensor Icon
Door Open and Trigger Alert Icon
N/A
N/A
37
