24-Hour Timer Mode
To enter 24-hour Timer Mode, press
a melody and the clock indicator will appear on the remote's LCD. Once in Timer Mode, the
system will remote start every 24 hours. Repeat this process to turn Timer Mode off.
Diagnostics
The system's microprocessor monitors and reports all active and violated zones when arming and
disarming. LED flashes indicate the active or violated zone; siren chirps indicate system status.

Arm/Disarm Diagnostics

The number of siren chirps will indicate the status of the system when arming and disarming. For
information on which zone is active or has been violated refer to the Table of Zones.

System Status Chirps

Action Number of Chirps
Arm 1
Arm 1 (3 second delay), 1
Disarm 2
Disarm 4
Disarm 5

Table of Zones

Zone DESCRIPTION
(LED Flashes)
1
Instant trigger - hood pinswitch
2
Instant trigger - a heavier impact
detected by the shock sensor
3
Door switch trigger
4
Instant trigger - for optional sensors
5
Ignition trigger
NOTE: The Warn Away® response does not report on the LED.
36
and simultaneously. The remote control will produce
Description
System armed
System armed with Bypass Notification
System disarmed
System disarmed with Tamper Alert
System disarmed NPC® active
LCD Icon
Hood Open and Trigger Alert Icon
Full Trigger Shock Sensor Icon
Door Open and Trigger Alert Icon
N/A
N/A
