TEUCER LR-4RGB Technical Specification

CONTROLLER AND RECEIVER
LR-4RGB/4RGBW and R3C
4 zones RF controller and 3 zones receiver for RGB LED strip
Product Description
The LR-4RGB/4RGBW rremote enables one to control up to
4 zones of RGB LED strips. Featuring a touch colour wheel
which offers smooth and continuous colour changing op-
tions, enabling creation of colourful static and dynamic ef-
fects.
Features
• Easy control of RGB LED strips.
• Single zone, two, three and four zone control.
• 2.4GHz wireless technology, remote distance of up to
30m.
• Operates with an LED indicator light for ease of use.
• Each remote can control one or more receivers.
• Control each zone separately or simultaneously
• PWM dimming enables flicker-less dimming
Technical Specification
Controller
Order Code
Type
Input Voltage
Operation Frequency
Dimension
Power
Receiver
Order Code
Type
Input Voltage
Current
Output
Note
Dimension
LR-4RGB/4RGBW
RF Remote
3VDC
2.4GHz
58.5x107x9mm (WxLxH)
battery CR2032
R3C
RF receiver
12-24VDC
3x4A
144-288)W
Constant voltage
33x97x18mm (WxLxH)
Product Image
Recommendation
RF technology allows for greater flexibility when it comes to
controlling simple or complex lighting installations without
the need of additional cabling.
There are some limitations where installations have the
receivers enclosed in electrical boxes or hidden away in a
ceiling , reducing the RF signal strength and therefore the
communication range.
In order to overcome these RF Signal restrictions we sug-
gest the following when synchronising our RF controllers
and receivers:
• Keep the distance within 10 meters from the controller
• to the receiver. The remote can operate up to 30mtrs if
signal is uninterrupted by obstacles.
• When expanding your lighting, always try and use a
signal repeater (PR-RGB), where possible.
• If your installation requires several RF receivers, ensure
the "master" receiver is positioned in the middle.
Brighter for longer
